Dowell High Quality Aluminum Laser Welding Machine With CE FDA Certification

Dowell High Quality Aluminum Laser Welding Machine With CE FDA Certification thumbnail-1
Dowell High Quality Aluminum Laser Welding Machine With CE FDA Certification thumbnail-2
Dowell High Quality Aluminum Laser Welding Machine With CE FDA Certification photo-1
Dowell High Quality Aluminum Laser Welding Machine With CE FDA Certification photo-2
US$ 6,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Dowell
Contact Supplier Request Quote Chat Now
Jinan Dowell Photoelectricity Equipment Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name Dowell
Model Number WY-200HZ, DW200A
Single Pulse Energy 90J
Pulse Width 0.1-20ms, 0.1-20MS
Wavelength 1064nm
Focal Spot Diameter 0.2mm~2mm, 0.2--2MM
Max. Output Power 200W, 200w
Dimensions 800*1000mm, 800*1000mm load200Kg
Usage Welding, welding
Power(W) 200w
Certification CCC, CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

                                    DW-200A laser welding machine



Specifications

aluminum laser welding machine
1.Welding any shapes products very well
2.CE ISO certificate
3.Automatic welding



Dowell high quality aluminum laser welding machine with CE FDA certification



Product Feature
Laser Cooling Machine
Panasonic and Sony,other imported parts adopted in the whole machine
German technology, maintainence for whole life
Adopt high-power laser power devices
Continuous work for 24 hours
*Aplication material:stainless steel,steel plate,iron plate and other metal and alloy;
*Super Welder laser welding word machine advantages:high accuracy,can weld small and complex typeface and LOGO,high speed,no chromatic aberration and trace after welding,with beautiful appearance,no need processing;
*Aim at advertising word industry,special king-size light path,arbitrary rotation for 360,higher flexible range;
*No protuberant welding spot on the welding surface,no need the process of polishing and burnishing,saving working time,graceful and steady for the structure;
*No noise and no pollution
Option CCD Monitor, welding result is much clearer.









Parameter
Max laser power 220W~250W
Laser wavelenth 1064 nm
Monopulse Max power  90J
Laser welding depth 0.1-1.2mm
Pulse width  0.1-20ms
Laser welding frequency   0.5-40Hz
Laser spot size adjusting range  0.2-2mm
Whole power consumption  ≤9KW
Power need  220V ±10%/50Hz/40A
 Standard configuration working table  800*1000mm load200Kg
Sight positioning CCD CCD synchronism high definition camera
Laser device vertical travel  ≥200mm
Laser device horizontal direction  200-800mm
Warranty 12 Months Offer





Samples

Dowell high quality aluminum laser welding machine with CE FDA certification

Application

Laser automatic welding can be Used to weld alloy and metal, such as gold, silver, platinum, stainless steel, titanium, nickel, tin, copper, aluminum, etc.The equipment have widely applied in aviation, spaceflight,watercraft, petrochemical industry, home appliances, medical equipment, instrument, electric, motor.



Packing & shipping



1.Durable plyooden case or as per required.



 2.The delivery lead time would be 12-15 working ddays after recieving the payment.



 3.As for the wholesalers/distributors,we could send the cargo by air,by sea or by railways via reliable forwarder



Dowell high quality aluminum laser welding machine with CE FDA certificationDowell high quality aluminum laser welding machine with CE FDA certification



Service

Dowell high quality aluminum laser welding machine with CE FDA certification



1. One year quality guaranty, the machine with main parts(excluding the consumables).shall be changed free of charge when if any problem during the warranty period.

2. Lifetime maintenance free of charge.

3. Free training course at our plant.

After-sale Service:



a) Technical support online service provided



b) Technical files service provided.



c) On-site training service provided.



d) Spare parts replacement and repair service provided.



About UsDowell high quality aluminum laser welding machine with CE FDA certification



 1.18 months quality guaranty, the machine with main parts(excluding the consumables) shall be



    changed free of charge if there is any problem during the warranty period.



2. Free training course at our place.



3. We will provide the consumable parts at an agency price when you need replacement.



4. Can help you solve problems online or by email in 24hrs, free technical support.



5. Our staff can be sent to your company to install or adjust if necessary.




Business Type                Manufacturer,Trading Company
Recent Transactions 7
Main Products Lase cutting machine, Lasr engraving machine,Laser marking machine
Location Shandong,China(Mainland)
Year Established 2010
Number of Employees 51-100 people
Total Annual Sales Volume US$50Million--US$100Million
Main Markets North America,South America,Eastern Europe,Southeast Asia,Africa
