Help CenterCab Forklift TG
US$ 1,000 - 50,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
MIMA
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Sit Type Electric Tow Tractor/ 6Ton/ TG60US$ 1,000 - 50,000MOQ: 1 Unit -
Electric Tow Tractor of Seated Type With 6.0 TonUS$ 1,000 - 50,000MOQ: 1 Unit
-
MiMA 2-6T Tow Tractor AC DCNegotiableMOQ: 1 Set
-
Forklift Fan TGUS$ 1,000 - 50,000MOQ: 1 Unit
-
Popular Electric Tow Tractor Forklift From MIMAUS$ 1,000 - 50,000MOQ: 1 Unit
Condition
New
Place of Origin
Anhui, China
Brand Name
MIMA
Model Number
TG60
Type
Other, TOW TRACTOR
Power Souce
DC Motor
Rated Loading Capacity
6000kg
Max. Lifting Height
1320 mm
Min. Lifting Height
110mm
Fork Length
0 mm
Fork Width
0mm
Overall Dimensions
2210*1070*1320mm
Certification
SGS,ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
cab forklift,TG series;Towing Capacity:2T,3T,6T,50T,100T;
High-power Battery;
cab forklift ,TG series;
With 2T,3T,6T,50T,100T towing capacity;
With High-power battery;
Lower center of gravity with perfect stability durig driving;
Easy maintanence;
Most used in airport,bus station,warehouse etc;
|
Descriptiom |
TG20 AC DRIVING |
TG30 AC DRIVING |
TG40 AC DRIVING |
TG60 DC DRIVING |
| Operate Type | Stand-on | stand-on | seated | seated |
| Rated Tow Capacity (KG) | 2000 | 3000 | 4000 | 6000 |
| Max Travelling Speed km/h-Laden/unladen | 4/6.7 | 4/6.7 | 5/7 | 8.8/10.5 |
| Min. Turning Radius --mm | 1160 | 1160 | 1350 | 1650 |
| Gradeability --% | 5 | 5 | 5 | 5 |
| Overall Length (MM) | 1300 | 1300 | 1925 | 2210 |
| Overall Width (MM) | 850 | 850 | 900 | 1070 |
| Overall Height (MM) | 1270 | 1270 | 1350 | 1320 |
| Wheelbase --mm | 975 | 975 | 1320 | 1290 |
| Height of Coupler center (from floow) | 140-240 | 140-240 | 295-365 | 270-320 |
| Wheel Type | rubber | rubber | rubber | rubber |
| Rear Wheel (MM) | Φ150*60 | Φ150*60 | Φ305*140 | 6.50-10 |
| Driving Wheel(MM) | Φ215*75*1 | Φ215*75*1 | 267*127 | 15*4.5-8 |
| Battery V/AH --Domestic Brand | 24/210 | 24/210 | 48/280 | 48/480 |
| Charger V/A | 24/30 | 24/30 | 48/30 | 48/50 |
| Driving Motor (KW) | DC1.2/AC1.5 | DC1.2/AC1.5 | 3 | 5.0 |
| Service Weight (with battery) KG | 600 | 600 | 870 | 1885 |
Company Information
ISO Certificate:
The more heavy tow tractor can be produced according clients' requirements,like the 50T,100T.....if you have any requirements or suggestion on that,pls don't hesitate to contact with us.
