Specifications
Strong laser beam keeps stable working positionFlat working table full of dots to absorb smoke very well
Large memory capacit
Application Field
Plastic and rubber industry, ads/crafts/presents industry,precise instrument/machine componnents,leather cloth industry.
Features
1. With imported USA RF metal laser tube which is characterized by excellent beam quality, stable performance and long lifetime.
2. .With imported gilded lens with silicon base and two-layer focusing system, the beam is sharper and cutting force is stronger.
3. The X.Y axis adopt imported linear guide rail and imported servo motor with speed-reducing driving system to make cutting stable and cutting surface smooth.
4. Double water-cooling system with self-protective function assures stable continuous running.
5.We offer two laser tube and two laser head for each equipment which can improve efficiency of the equipment.
Technical Parameter
Laser Generator |
Hermetic and detached CO2 laser tube |
Laser Power |
80W (60W,100W,150W ,180W for option) |
Cutting Area |
1600*1300mm |
Positioning Precision |
±0.01mm |
Control System |
Speedy DSP |
Supporting Format |
plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Support AutoCAD,CoreDraw |
Engraving Speed |
1000mm/s |
Cutting Speed |
500mm/s |
Interface |
LCD Screen and USB interface |
Working Voltage |
AC220V ±10%,50Hz |
Running Environment |
0-45°, Humidity: 5%-95% |
Warranty |
One year, except consumable goods |
