Home > Lights & Lighting > LED Outdoor Lighting > LED Point Light > 26mm Rgb DMX Led Disco Amusement Lights 5050smd

26mm Rgb DMX Led Disco Amusement Lights 5050smd

26mm Rgb DMX Led Disco Amusement Lights 5050smd thumbnail-1
26mm Rgb DMX Led Disco Amusement Lights 5050smd thumbnail-2
26mm Rgb DMX Led Disco Amusement Lights 5050smd photo-1
26mm Rgb DMX Led Disco Amusement Lights 5050smd photo-2
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
RGB 5050
Input Voltage(V):
12 V
Lamp Power:
0.72
Contact Supplier Request Quote Chat Now
Shenzhen Kingtar Technology Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen Zhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source RGB 5050
Input Voltage(V) 12 V
Lamp Power 0.72
Color Temperature(CCT) Other, changeable
Working Temperature(℃) -40, 60
Working Lifetime(Hour) 50000
Lamp Body Material Other
IP Rating IP67
Certification CE
Emitting Color RGB
Place of Origin Guangdong, China
Brand Name kingtar
Model Number KT-IC219

                                 26mm rgb DMX led disco amusement lights 5050smd

26mm rgb DMX led disco amusement lights 5050smd



---Production Description---

This led pxiel lighting source include 3 pieces RGB smd 5050 ( 3pin connectors ), Reliable and stable IC chip ucs2903 ( upgrades version of UCS1903) . It can be perfectly work with DMX controller,SPI  (SD card controller) Arduino

Passed CE ROHS .

Each 26mm RGB led pixel light can be addressable individually  ,can achieve full -color running water,chasing,scan results.depending on the composition changes can be  mounted in different color characters,patterns and other dynamic effects.with easy installation,high brightness,safety and  energy saving,long life,low attenuation





---Production Details---
Brand Name Kingtar
Model No KT-IC219
Power Consumption 0.72W
Work Voltage 12V
Viewing Angle 120°
LED Type 3 SMD 5050
Emitting Color RGB changeable
Protection Rate/IP Rating IP67
Operating Temperature -40-60
Certificate CE ROHS
LED life >50,000H
Packing 100pcs/bag,1000pcs/carton
Warranty 2 years
Product name 26mm rgb DMX led disco amusement lights 5050smd
Cover Milk/Transparent





---Production Features---



  1  Special fitting style, can be assembled directly after the hole was made

  2  Flexible to use, make it much easier to assemble the outdoor signboard

  3  Can be applied in different kinds of board, example the Electrogalvanized Metal Sheet, Au-P   board, metal board

  4  Parallel connection wire, when one is broken, others can keep lighting

  5  Controller can be applied, make the particular style for your requirement



---Production Application---



 a;Outdoor sign letters,replace the old neon signs.

 b; Outdoor signboard for different shops, KTV,Club nightclubs ,themed,shopping mall top, hotel and  building decoration

 c; DIY lighting and home decoration use



---Picture show---







 26mm rgb DMX led disco amusement lights 5050smd

  26mm rgb DMX led disco amusement lights 5050smd



 26mm rgb DMX led disco amusement lights 5050smd



  26mm rgb DMX led disco amusement lights 5050smd









26mm rgb DMX led disco amusement lights 5050smd



26mm rgb DMX led disco amusement lights 5050smd26mm rgb DMX led disco amusement lights 5050smd

26mm rgb DMX led disco amusement lights 5050smd

 26mm rgb DMX led disco amusement lights 5050smd

 Connection:

  1. Signal wire: DC+, DAT, GND

  2 .DC+ and GND connect to power supplier;DAT and GND connect to controller

  3 .Relative Controller: SPI controller support UCS1903; when use DMX decorder, can connect to DMX system

  4. Support online control



Our service:

 1 Reply your enquiry within the shortest possible time

 2 Experience staffs answer all your questions

 3 Discounts are offered based on order quantities

 4 Excellent after sale service

 5 reliable warranty



Trade Terms:



 1 . Payment Terms :

   T/T ; Western union; Paypal

2 . Delivery Time :

   Normally we had materials in stock  , Lead time: 3-7 working days

3.  Warranty :

  2 Years warranty

4. Delivery Ways :

  DHL, Fedex, TNT UPS, EMS door to door service, by sea, by air, etc
