Pixel RGB LED Rectangle Module WS2811

Name: Pixel RGB LED Rectangle Module WS2811
Brand: Kingtar
SKU: 108456589

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Model Number:

KT-M753

Chip Material:

AlGaInP

Emitting Color:

Tri-Color(Red-Blue-Green)

Shenzhen Kingtar Technology Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Model Number KT-M753

Chip Material AlGaInP

Emitting Color Tri-Color(Red-Blue-Green)

Power Other, 0.72

Color Rendering Index(Ra) 80

Color Temperature RGB

Operating Temperature(℃) -20, 50

Storage Temperature(℃) -20, 50

Place of Origin Guangdong, China

Brand Name Kingtar

Certification CE

Pixel RGB LED Rectangle Module WS2811

Product Features

WS2811 driver IC
Working voltage:12VDC
Each module contains a quantity of 3 piece SMD5050 RGB .
Epistar chip ,high brightness and quality
Hard plastic shell with clear waterproof sealant/epoxy over LEDs.
2000-2500 mcd total RGB
120 Beam Angle
20pcs per string ,please note to feed power in each string.
LED Life: 50,000 Hours typical
Wiring colors:The base of each module includes double-stick adhesive tape
- Red: 12v Positive / +
- Green: Data Signal
- Yellow: 12v Negative / -
20awg wire
Maximum recommended continuous length of modules is 20 in series. Longer lengths can result in lower light output.
Power consumption per module (three LED's per color):
- Red: 21ma (.414 amp per 20 modules)
- Green: 22ma (.431 amp per 20 modules)
- Blue: 22ma (.428 amp per 20 modules)
- White (all three colors): ~64ma (1.27 amp / 15.2 Watts per 20 modules)
- Power drop over 20 Modules from 12v: 11.3v
