Straddle Legs Automatic Electric Pallet Truck Stacker

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Straddle Legs Automatic Electric Pallet Truck Stacker
Model TB
Loading capacity: 1.0 / 1.5/ 2.0ton
Lifting height: 1600mm to

Straddle Legs Automatic Electric Pallet Truck Stacker

Model	TB10 -16	TB10 -25	TB10 -30	TB10 -35	TB15 -25	TB15 -30	TB20 -16
Load capacity Kg	1000	1000	1000	1000	1500	1500	2000
Load center mm	500	500	500	500	500	500	500
Max. lifting height mm	1600	2500	3000	3500	2500	3000	1600
Free lift mm	0
Wheel type	Polyurethane solid tire
Pedal length mm	500	500	500	500	500	500	500
Fork size(LxW) mm	1150*190
Width of forks(aptotic) mm	680	680	680	680	680	680	680
Overall length(The pedal is closed) mm	2040	2040	2040	2040	2040	2040	2040
Overall width mm	850	850	850	850	850	850	850
Overall height(mast closed) mm	2085	1805	2055	2305	1805	2055	2085
Overall height fork raised(with backrest) mm	2085	3036	3536	4036	3036	3536	2085
Outside turning radius mm	1725	1725	1725	1725	1725	1725	1725
Front wheel to fork tip mm	330	330	330	330	330	330	330
Aisle width for pallet 800x1200 lengthways	2480	2480	2480	2480	2480	2480	2480
Aisle width for pallet 1000x1000 crossways	2460
Lift speed,laden/unladen mm/s	70/108
Lowering speed,laden/unladen mm/s	78
Battery weight Kg	200
Max. walking speeds Km/h	4.0/5.8				4.0/5.8
Grade abitity %	8	8	8	8	8	8	8
Total weight( with battery) Kg	~880	~935	~950	~975	~940	~950	~905
Driving wheel mm	Φ215*75
Front wheel mm	Φ80*70
Balance wheel mm	Φ150*50
Battery V/Ah	24/210
Charger V/A	24/30
Driving motor Kw	1.5	1.5	1.5	1.5	1.5	1.5	1.5
Lifting motor Kw	2.0	2.0	2.0	2.0	2.0	2.0	2.0
Battery dimensions l/w/h mm	650200585
