Patent Fetal Stimulator Technology Maternal&Fetal Monitor With Twins Ctg Available
US$ 500 - 700
MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Maternal-Neonatal Ultrasonic Monitor
Brand Name:
Jumper
Model Number:
JPD-300P
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fetal Monitoring Equipment Jumper Fetal Monitor With 7'' and 12.1'' Tft Lcd DisplayUS$ 500 - 800MOQ: 1 Set -
Hospital Medical Equipment Jumper Ctg Fetal Monitor Jpd 600p Fetal&Maternal MonitorUS$ 460 - 800MOQ: 1 Unit
-
Patent Fetal Acoustic Stimulator Technology Ultrasound Machine, 7'' 12.1'' Fetal&Maternal MonitorNegotiableMOQ: 1 Unit
-
Medical Equipment ECG Machine Jumper 300P Ecg Fetal MonitorUS$ 480 - 800MOQ: 1 Unit
-
Fetal Monitoring Equipment JPD 300P Fetal Monitor With Fetal Stimulator TechnologyUS$ 500 - 700MOQ: 1 Unit
Type
Maternal-Neonatal Ultrasonic Monitor
Brand Name
Jumper
Model Number
JPD-300P
Product Description
Jumper FAS technology 7'' ultrasound machine, Maternal-Neonatal Ultrasonic monitor JPD-300P
Standard parameters:FHR,TOCO,Fetal movement
.Options:Materal 6 parameters:ECG PR RESP NIBP SPO2 TEMP
FAS( Fetal Acoustic Stimulator)
Twins monitor interface,Twins FHR measurement
Features:
1. Lightweight,space saving,easy operations,can be laid on or mounted
2. Interface of parameter of FHR,TOCO,Fetal movement(standard parameters),etc
3. Support pause and playback
4. TFT lcd display 7'',10.1'',12.1'' choose
5.Built-in long-life,HD themal parinter
6. Probe:high sentivity/waterproof/built-in FAS
7.Automatic grading function
8. Data storage 36 hours
9. DC(16.8v lithium battery) and AC(100V-240V,520Hz/60Hz)
10. Options: Twins monitor interface,Twins FHR measurement,FAS(fetal acoustic stimulator)
2. Interface of parameter of FHR,TOCO,Fetal movement(standard parameters),etc
3. Support pause and playback
4. TFT lcd display 7'',10.1'',12.1'' choose
5.Built-in long-life,HD themal parinter
6. Probe:high sentivity/waterproof/built-in FAS
7.Automatic grading function
8. Data storage 36 hours
9. DC(16.8v lithium battery) and AC(100V-240V,520Hz/60Hz)
10. Options: Twins monitor interface,Twins FHR measurement,FAS(fetal acoustic stimulator)
Patent FAS technology(What's FAS?)
FAS is Fetal awaking stimulator.We attached a vibriting device into the FHR probe.
When the fetus is sleeping,we can wake baby up with FHR probe vibrating.in order to get the accurate data.
There's no need to use another Fetal stimulator probe.More convenient to the users.
When the fetus is sleeping,we can wake baby up with FHR probe vibrating.in order to get the accurate data.
There's no need to use another Fetal stimulator probe.More convenient to the users.
Parameters:
3 in 1 transducer (U/S, TOCO and Remote Even market),U/S2 transducer(option), maternal Spo2 sensor(option), blood pressure cuff(option).
Main unit the main unit has the LCD module, recorder and electronic circuitry-microprocessor, signal processing, audio system, display systems and power supply. Signals from the transducers are processed and displayed on the large LCD display. And the menu can be adjust by encoder.
The key on control panel can be set up the system parameter ,freeze display , adjust volume,
printer control , alarm control and so on.
Transducer 3-in-1 transducer (include U/S, TOCO and Remote Event marker). The transducer are held in
Place on the abdomen by elastic straps. The pregnant woman hold the marker, push the button when she feels fetal moving or uterine activity.
Fetal Heart Rate:
Transducer: Multi-crystals, pulsed doppler , high sensitively
Strength: ,<5mW/cm2
3 in 1 transducer (U/S, TOCO and Remote Even market),U/S2 transducer(option), maternal Spo2 sensor(option), blood pressure cuff(option).
Main unit the main unit has the LCD module, recorder and electronic circuitry-microprocessor, signal processing, audio system, display systems and power supply. Signals from the transducers are processed and displayed on the large LCD display. And the menu can be adjust by encoder.
The key on control panel can be set up the system parameter ,freeze display , adjust volume,
printer control , alarm control and so on.
Transducer 3-in-1 transducer (include U/S, TOCO and Remote Event marker). The transducer are held in
Place on the abdomen by elastic straps. The pregnant woman hold the marker, push the button when she feels fetal moving or uterine activity.
Fetal Heart Rate:
Transducer: Multi-crystals, pulsed doppler , high sensitively
Strength: ,<5mW/cm2
Signal processing: special DSP system and modern recognization.
Working frequency: 1.0MHz
Measurement range: 50~210 bpm
Alarm Range:
High limit: 160,170,180,190 bpm
Low limit: 90,100,110,120 bpm
Maximum audio output power : 1.5 Watt
Toco:
Measurement range: 0~100 units
Maternal SpO2 measure:
Measure scope : 70%~99%.
Measure accuracy: ±3%
Pregnant HR Measure:
Measure scope: 30bpm~240bpm
Measure accuracy: ±2 bpm
NIBP measure:
NIBP-SYS (6.7~32.0Kpa)(50~240mmHg)
Working frequency: 1.0MHz
Measurement range: 50~210 bpm
Alarm Range:
High limit: 160,170,180,190 bpm
Low limit: 90,100,110,120 bpm
Maximum audio output power : 1.5 Watt
Toco:
Measurement range: 0~100 units
Maternal SpO2 measure:
Measure scope : 70%~99%.
Measure accuracy: ±3%
Pregnant HR Measure:
Measure scope: 30bpm~240bpm
Measure accuracy: ±2 bpm
NIBP measure:
NIBP-SYS (6.7~32.0Kpa)(50~240mmHg)
NIBP-DIA (3.4~26.6Kpa)(25~200mmHg)
NIBP-MEAN(2.0~24.0ka(15~180mmHg)
NIBP Accuracy: ±1.1kPa(±8mmHg)or ±5% of the results, take the bigger one.
Maximum Mean error : ±5mmHg
Maximum Standard deviation 8mmHg
Pulse Rate Accuracy: Maximum Mean error : ±2bpm
Measure accuracy: ±2 bpm or ±5% of the results, take the bigger one.
Measure mode: Manual
NIBP Accuracy: ±1.1kPa(±8mmHg)or ±5% of the results, take the bigger one.
Maximum Mean error : ±5mmHg
Maximum Standard deviation 8mmHg
Pulse Rate Accuracy: Maximum Mean error : ±2bpm
Measure accuracy: ±2 bpm or ±5% of the results, take the bigger one.
Measure mode: Manual
Interface:
The LCD displays FHR, TOCO, FM , maternal parameters , time, date, volume and so on, can be stroed and playback.
Power: AC100-240V,50/60Hz or 8.4 Li-LON
Power Consumption: < 20W
Dimension: 295W×240D×73H(mm)
Net weight:1.75kg
Working Environment: Temperature: 5~40°C. Relative humidity: 10~80%
Power: AC100-240V,50/60Hz or 8.4 Li-LON
Power Consumption: < 20W
Dimension: 295W×240D×73H(mm)
Net weight:1.75kg
Working Environment: Temperature: 5~40°C. Relative humidity: 10~80%
Detailed Images
Packing & Delivery
Configuration:
Main Body
Battery & Charger
FHR, TOCO, FM three in one probe
Belt & Gel
Power Cable
Printing paper
English User Manual
Package:
Package:2 units/Carton,13kg/Carton
Port: Shenzhen/HK
Delivery:5-10days after order confirmed
Payment terms: T/T,Western Union, Paypal
