Automatic Soldering Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Leady
Model Number:
LD-330
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Good Performance High Precision Three Axis Automatic Desktop Soldering RobotNegotiableMOQ: 1 Set -
Professional High-speed Auto Soldering Machine /automatic Welding Robot MachineNegotiableMOQ: 1 Set
-
Auto Soldering MachineNegotiableMOQ: 1 Set
-
Five Axis Desktop Automatic Soldering Robot (Solder 320)NegotiableMOQ: 1 Set
-
3 Axis Automatic Soldering Robot SD-450II-RNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Leady
Model Number
LD-330
Voltage
220v
Current
20A
Dimensions
510*440*780mm (L*W*H)
Weight
30KG
Usage
Tin soldering
Certification
ISO.CE
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Mode of motion:the robot operation is controlled by five axis driving under control software, to realize the accuracy positioning.
Welding manner:Soldering iron heating with constant temperature by high frequency eddy current
Working manner:Iron is moved to appointed soldering position by x/y setting, then implement soldering job by programming. The welding will be done by programming automatically , to get excellent soldering joint.
-Have spot welding , drag soldering , auto cleaning …etc. feature
-Have position calibration /copy / array and auto positioning …etc. operation in simple and quickly.
-fully parameter setting , completely guarantee the soldering quality
- 7’ touch panel, friendly interface and simple operation
Specifiction:
Outline size:510*440*780mm (L*W*H)
:320*275*55mm(X*Y*Z)
Drive by:step motor
Positioning:±0.02mm
Accuracy:±0.05°
Slider:HW
Control :PLC + 7’ TP
Program:256groups,400steps/group
wire feeding:feeding by programming
Control:impulse type high frequency constant Temp
Power:150W / 320W
COM : USB
Voltage:220VAC,50HZ
Air pressure :0.3Mpa
Weigh:30kg
:320*275*55mm(X*Y*Z)
Drive by:step motor
Positioning:±0.02mm
Accuracy:±0.05°
Slider:HW
Control :PLC + 7’ TP
Program:256groups,400steps/group
wire feeding:feeding by programming
Control:impulse type high frequency constant Temp
Power:150W / 320W
COM : USB
Voltage:220VAC,50HZ
Air pressure :0.3Mpa
Weigh:30kg
