Best Price Automatic Screw Locking Machine for Toys Screw-320

Best Price Automatic Screw Locking Machine for Toys Screw-320 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Leady
Model Number:
Screw 320
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Leady
Model Number Screw 320
Condition New
After-sales Service Provided Engineers available to service machinery overseas

Best Price Automatic screw locking machine for toys Screw-320

Parameter





Application:
Notebook computers, glasses, mobile phones, LCD monitors, watches, integrated board, 5C precision industries pay for the environment and efficient lock.

Feature:
Detection: slide lock ,floating teeth
PLC control system, automatic screw feeding, take screws, lock screws, can be any point in the stroke range, location data can be stored in the system and at any time. Optional with servo-driven, more accurate location,  faster movement.

Specification:
Outline size:500*620*630mm  (L*W*H)
Working Range: 320*390*70mm(X*Y*Z)
Drive mode:3 axis simple driver
Precision 0.02mm
Control sys:PLC + TP
Screw Feeding :Absorption type
Operation method  :Teaching Programming
Working Speed:Min<1.2S
Memory size:14groups, 40steps/group
COM: USB
Voltage:220VAC,50HZ
Air Pressure:0.4Mpa
Weight:60kg
Warranty:1year




Features

  • Easy to program - Dedicated fluid dispensing software eliminates the need for complex robot language programming
  • Programmable interface via teach pendant or PC
  • Fully integrated positioning and fluid dispensing functions
  • Suitable for many fluid dispensing applications

Fast, highly accurate and produce more parts with less process time

Common Application Range:

1.Semiconductor packaging
2.Fixing and protection of PCB electronic components
3.Packaging adhesion of LCD glass panel
4.Coating of panel of the mobile phone or dispensing of the key
5.Speaker dispensing
6.Dispensing seal of battery boxes
7.Coating of parts of vehicles and machines
8.Coating adhesion of hardware parts
9.Coating of rationed gas,liquid filling
10.Chip bonding



Our other product:

Best Price Automatic screw locking machine for toys Screw-320Best Price Automatic screw locking machine for toys Screw-320Best Price Automatic screw locking machine for toys Screw-320

Packing&Delievery:

Best Price Automatic screw locking machine for toys Screw-320

Best Price Automatic screw locking machine for toys Screw-320Best Price Automatic screw locking machine for toys Screw-320Best Price Automatic screw locking machine for toys Screw-320



Company Information:



 LEADYTECH is under Leady (HK) Group,located in OBO High Tech Park,Dongguan Nancheng District.Engaged in automation R&D,production. sales as one of high-tech enterprises.







Our wide range of high quality products include GU10/M16, bulb, TLED lamp manufacturing equipment, automatic assembly line, automatic aging test production line, etc..







Now become a leading enterprise in the contemporary intelligent automation manufacturing equipment after 10 years of automation equipment R&D. we are committed to effectively and efficiently serving the worldwide needs of our clients and exceeding their expectations in quality, price, service and speed.
