Stress control heat shrinkable protection sleeve for 36kv joints/terminations
- 1000000 Roll / Rolls per Month
- shenzhen
- Credit Card PayPal
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | VAST | Model Number: | HSC-360 |
| Type: | Insulator | Material: | PE | Application: | High Voltage |
| Rated Voltage: | 36kv | Tensile Strength: | ASTM D 2671 |
Packaging Details
it is according to your size
Product Description
Specifications
Stress control heat shrinkable protection sleeve1.electric stress relief
2.min shrinkable tem 100
3.effectively protection
Stress control heat shrinkable protection sleeve for 36kv joints/terminations
Features/Applications
HSC-360T is made from radiation cross-linked polyolefin material,The specially designed chemical formulation and carefully controlled manufacture technology effectively release the high electrical stress present at insulation termination of power cables terminations up to 36KV.
Minimum shrink temperature: 100°C
Minimum fully recovery temperature: 130°C
Technical data:
Property | Test Method | Typical Data |
Tensile strength | ASTM D 638 | ≥10MPa |
Elongation at break | ASTM D 638 | ≥300% |
Heat Shock (200°C/30mins) | ESI09-13 | No splitting, cracking dropping or flowing after 30 mins at 200°C |
Dielectric constant | IEC 250 | ≥45 |
Volume Resistance | IEC 93 | ≥109Ω .cm |
Low Temp Flexibility |
| No cracking after 4hrs at -20°C(max) |
Water absorption | ISO 62 | <1.0% |
Longitudinal shrinkage | -- | ±5% |
Eccentricity | ASTM S 2671 | <35% |
Normal size (mm) | As supplied (mm)
| After recovered (mm) | *Style
| Standard Length
| |
Inside diameter (min.) | Inside diameter (Max.) | Wall thickness (Nom.)
| |||
Continuous length tubing | |||||
47/18 | 47 | 18 | 2.5 | - | 30M/Spool |
Cut length tubing
| |||||
55/21 | 55 | 21 | 2.5 | 0 | 1000mm |
65/25 | 65 | 25 | 2.5 | 0 | 1000 mm |
75/30 | 75 | 30 | 2.5 | 0 | 1000 mm |
95/45 | 95 | 45 | 3.0 | 0 | 1000 mm |
Company Profile
We are located in Dongguan and are specialized in manufacturing PVC tubing. With an experienced and professional team, we have exported our products to many countries and regions all over the world, especially the European Union.
Our company have more than ten years of production and developing experiences ,with perfect equipment and design ability.
Our products enjoy a good reputation among our customers. We welcome customers, business associations and friends from all parts of the world to contact us and seek cooperation for mutual benefits.
