Specifications
12v 24v 48v 300ah lifepo4 battery pack for car2000 times cycle
24 month warranty
Super power Batteries (Lithium Batteries) Manufacturer---Shenzhen Auto-Energy Technology Co.,Ltd
-
P
-
Soft pack, barren liquor ,excellent security, need not safety valve
· Large capacity . long cycle life, high energy density
· Low internal resistance, low self-discharge rate
· Superior performance in rate discharging
· 360 degree in any display, high space utilization
· Wide operating temperature : -20-55 degree
-
1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car
2. Light electric car: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair
3. E-tool: electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices, Telecom base Station
6. Small medical equipment and portable equipment
Item |
Basic parameters |
Model |
12V300AH |
Material of Anode/Cathode |
LiFePO4/Graphite |
Size |
270(T)×340(W)×295(H)(mm) |
Weight |
About 38Kg |
Nominal capacity |
300Ah |
Nominal Voltage |
12V |
Internal resistance |
≤8mΩ |
Energy density |
≥130Wh/kg at 0.2CDC |
Volumetric energy density |
≥220WH/L at 0.2CDC |
Discharge cut-off voltage |
8V |
Charge voltage |
14.6V |
Standard charging |
0.2C constant current charge to 14.6V, then constant voltage 14.6V charge till charge current decline to≤0.05C |
Standard discharging |
0.2C CC discharge to 8V. |
Low temperature performance |
0.2C capacity higher than 70% of nominal capacity under -20°C |
High temperature performance |
0.5C capacity higher than 98% of nominal capacity under 55°C |
Standard charge/discharge cycle life |
Cycle life of standard charge/discharge capacity after 2000 cycles greater than 80% of initial capacity |
Max .continual charge current |
100A |
Max. continual discharge current |
400A |
Max. Charge/discharge pulse current (10S) |
600A |
Operating temperature |
Charging: 10~45°C, Discharging:-20~55°C |
Storage temperature |
Less than 1 year: 0~25°C Less than 3 months:-10~45°C |
Our typical product ( battery is customized from 10-300ah for cell!!!)
No |
Model |
Nominal capacity (AH) |
Nominal voltage (V) |
Size (mm) |
Cycle life |
1 |
LFP10215160P |
20AH |
3.2V |
10*215*160 |
³ 2000 |
2 |
LFP10460320P |
100AH |
3.2V |
10*460*320 |
³ 2000 |
3 |
LFP15210260P |
60AH |
3.2V |
15*210*260 |
³ 2000 |
4 |
LFP10320230P |
50AH |
3.2V |
10*320*230 |
³ 2000 |
5 |
LFP20320230P |
100AH |
3.2V |
20*320*230 |
³ 2000 |
6 |
LFP18460320P |
200AH |
3.2V |
18*460*320 |
³ 2000 |
7 |
LFP380380S |
20AH |
3.2V |
Diameter38*H380 |
³ 2000 |
8 |
LFP75380S |
100AH |
3.2V |
Diameter75*H380 |
³ 2000 |
9 |
LFP55380S |
50AH |
3.2V |
Diameter55*H380 |
³ 2000 |
10 |
LMT55380S |
45AH |
2.4V |
Diameter55*H380 |
³ 20000 |
11 |
LFPT55380S |
45AH |
1.8V |
Diameter55*H380 |
³ 20000 |
12 |
12V100AH |
100AH |
12V |
70*340*295 |
³ 1500 |
14 |
48V50AH |
50AH |
48V |
260*380*260 |
³ 1500 |
15 |
LMO55200S |
30AH |
3.7V |
Diameter55*H200 |
³ 1000 |
What we can do:
1. All of our products have proceeded comprehensive testing before shippment;
2. Support imprint your logo on products;
3. OEM orders are warmly welcome!
Warranty and Return:
1. All products have been tested before ship out;
2. All products have 1 year warranty. ( We will Changing or Refunding our products if problems appearanced in 1 year, in the case of correct operation according to the technical specification.)
3. We own the best after-sale service. If any problems happen, our team will do our best to solve for customers.
Should the battery or similar product be of interest to you, please contact me for further details including price.
