Specifications
Material system ( included LFP/ LMO/ NMC) ,dimension and performance parameter can be customized.
Item |
Basic parameters |
Model |
24V100AH |
Material of Anode/Cathode |
LiFePO4/Graphite |
Size |
165(T)×250(W)×315(H)(mm) |
Weight |
About 21.2Kg |
Nominal capacity |
100Ah |
Nominal Voltage |
24V |
Internal resistance |
≤8mΩ |
Energy density |
≥130Wh/kg at 0.2CDC |
Volumetric energy density |
≥220WH/L at 0.2CDC |
Discharge cut-off voltage |
16V |
Charge voltage |
29.2V |
Standard charging |
0.2C constant current charge to 29.2V, then constant voltage 29.2V charge till charge current decline to≤0.05C |
Standard discharging |
0.2C CC discharge to 16V. |
Low temperature performance |
0.2C capacity higher than 70% of nominal capacity under -20°C |
High temperature performance |
0.5C capacity higher than 98% of nominal capacity under 55°C |
Standard charge/discharge cycle life |
Cycle life of standard charge/discharge capacity after 2000 cycles greater than 80% of initial capacity |
Max .continual charge current |
100A ( 1C) |
Max. continual discharge current |
200A (2C) |
Max. Charge/discharge pulse current (10S) |
400A (4C) |
Operating temperature |
Charging: 10~45°C, Discharging:-20~55°C |
Storage temperature |
Less than 1 year: 0~25°C Less than 3 months:-10~45°C |
Product Characteristics:
· Soft pack, barren liquor ,excellent security, need not safety valve
· Long cycle life, high energy density
· Low internal resistance, low self-discharge rate
· Superior performance in rate discharging
· 360 degree in any display, high space utilization
· Wide operating temperature : -20-55 degree
Applications:
EV: electric motorcycle, pure electric car, pure electric bus, HEV etc.
Storage: solar and wind complementary stored energy streetlights, energy storage systems, household energy storage.
Power Supply: communication base station power supply, UPS, emergency power supply etc.
