24v Lithium Battery Packs for Electric Car,e-bike

US$ 866 - 1,000 MOQ: 1 Pack

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AET

Model Number:

24V100AH

Shenzhen Xinyongfeng Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AET

Model Number 24V100AH

Composed Type Other, Composed Type: 8 serials

Type Li-Ion

Size 165(T)*250(W)*315(H)(mm)

Voltage 24V

Weight 21.2Kg

Nominal Capacity 100AH

Application car ,UPS, solar and wind energy storage

Specifications

24v lithium battery pack for electric car,e-bike
1,CE ,MSDS ,ISO certifications
2,high energy density
3,more than 3000 cycles

Product Description

24v lithium battery packs for electric car,e-bike

Item	Basic parameters
Model	24V100AH
Material of Anode/Cathode	LiFePO4/Graphite
Size	165(T)×250(W)×315(H)(mm)
Weight	About 21.2Kg
Nominal capacity	100Ah
Nominal Voltage	24V
Internal resistance	≤8mΩ
Energy density	≥130Wh/kg at 0.2CDC
Volumetric energy density	≥220WH/L at 0.2CDC
Discharge cut-off voltage	16V
Charge voltage	29.2V
Standard charging	0.2C constant current charge to 29.2V, then constant voltage 29.2V charge till charge current decline to≤0.05C
Standard discharging	0.2C CC discharge to 16V.
Low temperature performance	0.2C capacity higher than 70% of nominal capacity under -20°C
High temperature performance	0.5C capacity higher than 98% of nominal capacity under 55°C
Standard charge/discharge cycle life	Cycle life of standard charge/discharge capacity after 2000 cycles greater than 80% of initial capacity
Max .continual charge current	100A ( 1C)
Max. continual discharge current	200A (2C)
Max. Charge/discharge pulse current (10S)	400A (4C)
Operating temperature	Charging: 10~45°C, Discharging:-20~55°C
Storage temperature	Less than 1 year: 0~25°C Less than 3 months:-10~45°C
