Condition New
Place of Origin Zhejiang, China
Brand Name Goodsense
Model Number FDS30
Type Other, Diesel side loader
Power Souce Diesel Engine
Rated Loading Capacity 3000kg
Max. Lifting Height 3600mm
Min. Lifting Height 160mm
Fork Length 1070 1220mm
Fork Width 125mm
Overall Dimensions 4555*2000*2460mm
Certification CE/ISO9001
After-sales Service Provided Engineers available to service machinery overseas
Product Description


3ton diesel side loader with japanese and chinese engine for sale



Specifications of  3ton Diesel Side Loader
Model
FDS30
Power type
diesel
Rated capacity
kg
3000
Load center
mm
500
Lift height
mm
3600
Forksize(L*W*T)
mm
1070x125x45
Mast tilt angle(F/R)
deg
6°/6°
Front overhang(wheel center to fork face)
mm
700
Ground clearance(bottom of mast)
mm
160
overall dimension(L*W*H)
mm
4555x2000x2460
platform width
mm
1200
platform length
mm
4555
overhead guard height
mm
2460
Turning radius(outside)
mm
4250
Travel(empty load)
km/h
17
Lifting(full load)
mm/s
310
Max. gradeability
%
20
Front Tire
2x28x9-15-12PR
Rear Tire
2x28x9-15-12PR
wheelbase
mm
2550
service weight
kg
2590
Battery  voltage/capacity
v/ah
12/80
Engine Model
A498BPG-78
manufacture
XINCHAI
rated output/r.p.m.
kw
45/2500
rated torque/r.p.m.
n.m
193/1800
no. of cylinder
4
bore x stroke
mm
98X105
displacement
cc
3168
fuel tank capacity
L
75
Transmission Type
hydraulic
Stage FED/RVS
1/1
operating pressure for attachment
Mpa
14

Main Features

1) Innovative Design;
2) Simplified Serviceability;
3) Enhanced Productivity;
4) Wide-view Mast -- offer enhanced forward visibility, thus more efficiency and safty during operation;
5) Solid Overhead Guard -- specially designed for additional security;
6) Ergonomics Seat -- much more comfortable and fatigue-relieve able after long time operation;
7) Powerful Engine -- imported brand engine ensures high performance, safty and efficiency;
8) Super low & Non-slip step.

Packing & Delivery
Our Company
Certifications
Our Service

Pre-Sales Service                                                                     Sales Service


* Inquiry and consulting support.

* View our Factory.

* Inquiry and consulting support.

* View our Factory.

We can supply the following product for you: 1-48Ton Diesel Forklift; 1-12Ton Electric Forklift; 1-7Ton LPG Forklift; CNG Forklift; 1.2-2Ton Electric Pallet Stacker; 1.3-3Ton Electric Pallet Truck; 2-3Ton Manual/ Hand Pallet Truck; 1.5-2.5Ton Reach Lift Truck; 2-3.5Ton Rough Terrain Forklift; 3-12Ton Side Loader; 1.6-2Ton Three Wheel Forklift.

We also can provide attachment for you, for example, paper roll clamp; bale clamp/pulp bale clamp; carton clamp; pusher/puller; pushoff; rotator; block clamp; drum clamp; fork clamp; fork positioner; fork extension; side shifter.etc.
