Product Description:
Product Name:NHYJV power cable/power cable
Material:Copper core /PVC insulation
Features:
1.used for power transmission and distribution
2.Rated Voltage:0.6/1kv 3.Temperature:<70
3.Produced according to GB/T 12706-2008,ie, IEC60502 standard.
4. No. of core: Single-core, Two-core, Three-core, Four-core, Five-core,Three core and earth(Three primary conductor and one Neutral conductor), Three core and two((Three primary conductor and Two Neutral conductor), Four core and earth((Four primary conductor and One Neutral conductor).
5. The highest allowed operating temperature of conductor for long-term working is 70oC. In short-circuit (Max. long-term is no more than 5 seconds). The highest temperature for conductor is no more than 160oC.
5. The environment temperature should be no lower than 0oC when lay. Otherwise it should be preheated.
Type |
Name |
Application |
VV |
Copper conductor ,PVC insulated, PVC sheathed electrical cable |
For laying in doors,in tunnel or cable trench, unable to bear external mechanical forces,S ingle core cable in magnteicduct is not permissible |
VLY |
Aluminum conductor ,PVC insulated, PVC sheathed electrical cable |
|
VY |
Copper conductor,PVC insulated , PE sheath electrical cable |
|
VLY |
Aluminum conductor ,PVC insulated, PE sheathed electrical cable |
|
VV22 |
Copper conductor ,PVC insulated, steel tape armoured,PVC sheathed electrical cable |
For laying in doors,in tunnels,in cable trench or direct buried,able to bear external mechanical forces, but unable to bear large pulling force. |
VLV22 |
Aluminum conductor ,PVC insulated, steel tape armoured,PVC sheathed electrical cable |
|
VV23 |
Copper conductor ,PVC insulated, steel tape armoured,PE sheathed electrical cable |
|
VLV23 |
Aluminum conductor ,PVC insulated, steel tape armoured,PE sheathed electrical cable |
|
VV32 |
Copper conductor ,PVC insulated, fine steel wire armoured,PVC sheathed electrical cable |
For laying indoors,in tunnels,cable trench, well or direct buried,able to bear external mechanical forces and determinate pulling force. |
VLV32 |
Aluminum conductor ,PVC insulated, fine steel wire armoured,PVC sheathed electrical cable |
|
VV33 |
Copper conductor ,PVC insulated, fine steel wire armoured,PE sheathed electrical cable |
|
VLV33 |
Aluminum conductor ,PVC insulated, fine steel wire armoured,PE sheathed electrical cable |
Company Profile:
Xiangtan Shenzhou Special Cable Co., Ltd is started in 2003 and located in Xiangtan,Hunan.China with more than 1180 employees. It covers an area of 40000 square meters.The predecessor of our company is Xiangtan Cable Factory, which established in 1951 ,once the biggest range of production in south of china.After purchased in 2003,at present,we have had first-class have domestic and imported equipment 1500 sets for production and detection ,providing adequate guarantee for manufacturing high quality cables. We have obtained CE,ABS,BV and DNV.
All of our products comply with international quality standards and can meet the needs of both domestic and overseas markets. Meanwhile, our management team strives to focus on "technology and development", which is regarded as the core of excellent production.
We have strong technical strength. We produce electric wires and cables, such as power cables, control cables, shielding cables, coaxial cables, fire-resistance cables, etc. We are also able to design special cables according to customers' requirements.
