3 Layers Pvc Concrete Template Board Co-extrusion Machine

3 Layers Pvc Concrete Template Board Co-extrusion Machine thumbnail-1
3 Layers Pvc Concrete Template Board Co-extrusion Machine photo-1
US$ 100,000 - 125,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Plates
Plastic Processed:
Other, PVC, PVC resin
Contact Supplier Request Quote Chat Now
Qingdao Deerma Plastic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Plates
Plastic Processed Other, PVC, PVC resin
Screw Design Double-screw
Automatic Grade full automatic
Place of Origin Shandong, China
Brand Name DEERMA
Model Number SJSZ-80/156
Voltage 380V/3P/50HZ
Power(W) 385kw
Dimension(L*W*H) 25*25*3m
Weight 10T
Certification CE/ISO9001/SGS
After-sales Service Provided Engineers available to service machinery overseas

Specifications

3 layers pvc concrete template board co-extrusion machine
1.turnkey project with low price
2.all imported electrical parts

3 layers pvc concrete template board co-extrusion machine

Production Description
 3 layers pvc concrete template board co-extrusion machine
  • High efficiency conical twin screw extruder or parallel twin screw extruder .
  • It can produce transparent PVC soft and rigid sheet and free foam board .
  • The thickness is from 3mm to 30mm, width is from 1200mm to 2050mm.
  • This sheet is mostly used in transportation , advertisement,furniture industry ect.
NameValue
BrandDEERMA  3 layers pvc concrete template board co-extrusion machine
ModelSJSZ 80/156
Raw MaterialsPVC Powder
Voltage380V/3P/50HZ
Total power 385 KW
Extrusion output 200-500 KGS
Place of OriginChina
Year2012
CertificationISO9001, CE,SGS

Final product specification

W:1200mm, Thickness:3-30mm
Production Capacity 5 Sets/ per Month
Warranty12 Month



Production Line



1.Extruder:SJZ80/156 Conical twin extruder



3 layers pvc concrete template board co-extrusion machine





2.T Die Mould



3 layers pvc concrete template board co-extrusion machine







3.Forming machine



3 layers pvc concrete template board co-extrusion machine







4.Cooling bracket



3 layers pvc concrete template board co-extrusion machine







5.Haul-off unit



3 layers pvc concrete template board co-extrusion machine







6.Cutting unit in Length and breadth





3 layers pvc concrete template board co-extrusion machine



Application
  • These foam board is mostly used in transportation , advertisement, funiture industry and so on.



 3 layers pvc concrete template board co-extrusion machine



Shipping
  1. From Qingdao port by Sea
Payment

T/T: 30% TT in advance,balance upon  3 layers pvc concrete template board co-extrusion machine finished

  1. TT+L/C:30%TT,70 L/C at sight.
Certification
3 layers pvc concrete template board co-extrusion machine
3 layers pvc concrete template board co-extrusion machine
Packing
After inspection the complete machine line are packed in stretch film and then carefully packed in wooden box.

3 layers pvc concrete template board co-extrusion machine

Services

1.Equipment Installation



After the arrival of  1220mm wpc pvc foam board machine to the buyer’s country,seller will send engineer to the buyer’s factory in 15days to help install the machine line,and train the workers.



2.Equipment Warranty



Our company(Qingdao Deerma Plastic Machinery Co.,Ltd) would like to promise the good quality with 12months.During the warranty,no purposely and artificially damage,we will maintain or replace for free.After the warranty,if buyer need to replace the worn part,only pay the cost price,supply lifetime.



NOTE:Just tell us what is your request, we believe our machine could meet your request!!!
About US
QINGDAO DEERMA PLASTIC MACHINERY CO.,LTD with its research center has invested heavily in technical innovation to create new manchines. They have devoted themselves to researching the international markets to meet the needs and pride themselves with the ability to introduce new and different technology. All research and development, design, and production is now all done in house
