Machines For PVC WPC Door Panels
WPC door panel production line
WPC door panel extrusion line
WPC door extrusion machinery
WPC door panel machine
WPC PVC door extrusion machinery
WPC plastic machine
What is Features of our WPC door panel machine?
1.Our WPC machine has features of low consumption,low noise,stable running..
2.This WPC machine include:extruder,mould,vacuum calibration table,haul-off machine,cutter and stacker.
3.The extruder of WPC machine adopt special wpc screw and barrel for extrusion.With different mould,WPC machine
can produce wpc products with different shapes.
Flow Process
1.PE/PP+wood extrusion line craft:
Wood milling(wood powder,rice husk)—— Mixer(plastic+wood)——Granulator——Wpc extrusion line+Auxiliary
2.PVC+wood extrusion line craft:
Wood milling(wood powder,rice husk)——Mixer(plastic+wood)——Wpc extrusion line+Auxiliary
Technical parameter
| Model | YF600 | YF800 | YF1000 | YF1250 |
| Max.width of product(mm) | 600 | 800 | 1000 | 1200 |
| Extruder mode | SJZ80/156 | SJZ80/156 | SJZ92/188 | SJZ92/188 |
| Extrusion capacity(kg/h) | 280 | 280 | 600 | 600 |
| Motor power(kw) | 55 | 55 | 132 | 132 |
| Cooling water(cubic meter per hour) | 10 | 12 | 15 | 18 |
| Compressed Air (cubic meter per minite) | 0.6 | 0.8 | 1.0 | 1.2 |
Main Composition
| Item | Quantity |
| SJSZ- XX Twin Screw Extruder with Automatic Feeding System | One set |
| Die Mold & Stock Mold | One set |
| Vacuum Calibrarion Table | One set |
| Traction Machine | One set |
| Cutting Machine | One set |
| Automatic Stacker | One set |
| Electric Control System | One set |
Application
Wpc-plastic foam door panel extrusion line mainly use PVC+ wood powder to extrude wood-plastic panel such as integral door panel, builing template, cabinet door, window board, waincost, etc
Machine's Photos
1.Twin screw extruder with Automatic feeding system -- SJZ xx series conical twin screw extruder: (The model according to the sizes of final products to choose ) The specially designed screw and the advanced controlling system ensure excellent plasticization, high output and stable extruding.
2.Die Mould and Stock Mould (Matches or according to customer's drawings or samples)
Mould adopts high-quality alloy steel and throttling device to ensure even pressure of feed influent at the mould lips, and also differential action of up-down piece guarantee even thickness of the plate.
3.Vacuum calibration table
Heating exchanging and cooling system of quick speed in calibrating system alternate effectively and ordinally with vacuum system, which ensures calibrating precision. Vacuum system composes two independent subsystems and each is equipped with several fixed circulating vacuum lines of three-point type. Meanwhile, each line carries vacuum regulating system and vacuum display system that realize even and stable vacuum degree of plate surface.
4.Traction Machine
| Caterpillar tractor | Three groups or four groups |
| Type of caterpillar clamping | Air Cylinder |
| Effective tractor | W1000* L1300mm |
| Tractor motor power | 11kw |
| Frequency Control |
5.Cutting Machine
| Cross section cut | Rotating saw blade |
| Effective cytting width | 800-1000mm |
| Dust collector | one set |
6.Automatic Stacker
| Transmission roll | one set |
| Material | Stainless steel |
| Transmission motor | one set |
| Fixed-length devices | one set |
7.Electric control system
| Temperatue meter | Omron |
| Contactor | Schneider |
| Relay | Schneider |
| Transducer | Holip |
| Power light, button | Schneider |
| Inveter | ABB |
Trade Terms
Payment: T/T, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before deliverying.
Delivery Time: 30-45 days
MOQ: 1set
Our Certification
Company Review
Imported Electic Parts for your choice!
Best Services
1.Our company will provide relevant information on various technology and business consulted by customers. If clients want to visit our company, we will offer all they need for convenience.
2.After signing contract, company designs groundsill installation chart for water, electricity and gas of equipment basing on real condition and customers’ requirements and provides detail order list and matching manufacturer for reference for customer.
3.After equipment arrival, our service personnel will arrive at posted locale for installation, debugging, training and technology transfer till customers can operate independently and manufactures eligible product. Service personnel have to arrive at customer’s locale in time when we provide service for client again.
Why Choose us
1.We are China Leading Plastic Machine Manufacturer.
2.Alibaba Assessed 7 years Domestic Supplier .
3.Inspected by the Inspection Institution of SGS Certification.
4.100% QC inspection Before Shipmeng.
5.Best Quality & Best Service with Competitive price.
We have two this production lines in our showroom for other customer , welcome to visit our factory
