pvc building template board production line
Our WPC/PVC crust foam board machine includes the special twin-screw extruder , mold and other auxiliary machines , we use twin-screw extruder with compact structure. Superior performance. Besides the screw and barrel and die are designed by our company and made in world famous manufacturers. And use the high-performance alloy steel for professional processing. So the machine has the advantages of uniform plasticizing stable extrusion. High output and long life.
We can supply you the best material formulation and all of technology. We have several thousand kind of formula through 9 years’ researches, pvc or wpc foam board production line with big output, stable extrusion, high foaming, good and wear-resisting surface and so on
Work flow
PVC powder +additive → mixer →SJSZ series extruder →Coat-hanger type mould →Vacuum calibration cooling platform →cooling rollers and edge-cutting device →Haul off →stacker
Usage
It is widely used as building templates, industrial packing, furniture cabinet, outdoor landscapes material and indoor decoration and so on.
Technical information
Extruder |
Width of WPC crust foam board |
Thickness of WPC crust foam board |
Output capacity |
SJSZ-80/156 |
1220mm |
<25mm |
350Kg |
SJSZ-92/188 |
1830mm |
<25mm |
800Kg |
Description |
Parameter |
Feed material |
PVC+ assistant materials(also can add wood powder |
Product size |
1220*2440*5-20mm |
Production line speed |
0.8-1.5m/min |
Max. output |
350-500kg/h |
Outline size |
25×2.5×3 L×W×H(m),unsaturated |
Weight |
16T |
Total power |
255kw |
Actual energy consumption power |
210kw |
Main composition
| No. | Part. | Qty. |
| 1 | SJSZ80/156 Conical Double-screw Extruder | 1set |
| 2 | Mould | 1set |
| 3 | Calibration Forming Table | 1set |
| 4 | Cooling Bracket | 1set |
| 5 | Haul-off Unit | 1set |
| 6 | Transverse Cutting Bracket | 1set |
| 7 | Trim Cutting | 1set |
| 8 | Stacker | 1set |
Auxiliary Machines for your choice
| No. | Part. | Qty. |
| 1 | SHRL500/1000 Mixer | 1set |
| 2 | SWP-400 Crusher | 1set |
| 3 | SMP-500 Miller | 1set |
| 5 | Water Chiller | 1set |
Now we have machines in stock,sincerely invite you to vist our factory!
Also you can contact me for machine's running video.
