Home > Industrial Equipment & Components > Welding & Soldering Supplies > Welding Rod > Quality Aws A5.1 E6013xx

Quality Aws A5.1 E6013xx

Name: Quality Aws A5.1 E6013xx
Brand: RATNA 6013 XX
SKU: 108283433
Availability: InStock

Negotiable MOQ: 1 Metric Ton (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

India

Brand Name:

RATNA 6013 XX

Model Number:

AWS A5.1: E6013XX

Contact Supplier Request Quote Chat Now

Raajratna Electrodes Private Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Mumbai/ Mundra/ Pipavav

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin India

Brand Name RATNA 6013 XX

Model Number AWS A5.1: E6013XX

Material Other, Miled Steel

Length 350mm,450mm

Diameter 2.5mm,3.2mm,4mm,5mm

Application Ship hull construction and repair & maintenance of pressure vessel.

300-450mm length electrode welding rod

RATNA 6013 XX

Heavy coated rutile type all position welding Electrode for structural steel welding.

CLASSIFICATION : AWS/SFA-5.1: E 6013 , BS 639 E4322RR21
IS-814: ERR 4222 X , DIN 1913 E 4322RR622

APPROVAL : BIS

CHARACTERISTICS : An all position, heavy coated, radiographic electrode with exotic finish weld deposit. Weld bead is smooth and shiny. Electrode is designed to achieve high welding efficiency and gives excellent mechanical and chemical properties coupled with property of auto slag removal.

APPLICATION :
1) Suitable for boilers.
2) Heavy section.
3) Ship hull construction and repair & maintenance of pressure vessel.
4) Structural works.
5) Rail coaches/ wagons.
6) Locomotive fire boxes, coach panel & bridging wide root gap.

RE-DRY CONDITION : Re-Dry the electrode at 120°C for 30-60 minutes, for best results.

ALL WELD CHEMICAL COMPOSITION %

C	Mn	Si	S	P
0.10 max.	0.40-0.60	0.30 Max	0.030 Max	0.030 Max

ALL WELD MECHANICAL PROPERTIES :

YS (N/mm²)	UTS (N/mm²)	EL % (l=4d)	CHARPY “V” NOTCH IMPACT AT
350-460	440-540	22-32	0°C : 50-80 J

DIMENSION, CURRENT CONDITION & PACKING DATA

Size(mm) (DXL)	Size(inch) (DXL)	Current Condition (DC-/AC) Amps	No. of Pcs./pkt.	No. of Pcs./Case
2.50/ 2.40X350	3/ 32”X14”	60-90	200	800
3.15/ 3.20X350/ 450	1/ 8”X14”/ 18”	90-130	125	500
4.00X350/ 450	5/ 32” X 14/ 18”	140-180	75	300
5.00X450	3/ 16” X 18”	180-210	55	220
