RUTILE COATED WELDING ELECTRODE

RUTILE COATED WELDING ELECTRODE thumbnail-1
RUTILE COATED WELDING ELECTRODE photo-1
Negotiable MOQ: 1 Metric Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Gujarat, India
Brand Name:
RATNA 6013 X
Model Number:
AWS/SFA-5.1: E 6013X
Contact Supplier Request Quote Chat Now
Raajratna Electrodes Private Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Mumbai/ Mundra/ Pipavav
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Gujarat, India
Brand Name RATNA 6013 X
Model Number AWS/SFA-5.1: E 6013X
Material Other, Miled Steel
Length 300mm,350mm,450mm
Diameter 2.5mm,3.2mm,4mm,5mm
Application Pressure vessels.Heavy structures.Ship construction

RUTILE COATED WELDING ELECTRODERUTILE COATED WELDING ELECTRODERUTILE COATED WELDING ELECTRODERUTILE COATED WELDING ELECTRODE





300-450mm length electrode welding rod

RATNA 6013 X

Medium heavy coated rutile type all position welding Electrode for Carbon steel.

 CLASSIFICATION          : AWS/SFA-5.1: E 6013 , BS 639 E4322R21
                                            IS-814: ER 4222 X,DIN 1913 E 4322R3

APPROVAL                     : BIS, CIB, ABS, IRS, BV, BAX, PDIL , Toyo, BHEL

CHARACTERISTICS     : A medium heavy coated rutile type all position welding electrode with weld deposit of radiographic quality. The electrode can be subjected to low OCV, offer smooth rippled bead appearance coupled with low spatter and fumes.

APPLICATION              :
1) Suitable for storage tanks.
2) Rail coaches.
3) Pressure vessels.
4) Heavy structures.
5) Ship construction
6) Structure works, Boilers etc

RE-DRY CONDITION  : Re-Dry the electrode at 120°C for 30-60 minutes, for best results.


ALL WELD CHEMICAL COMPOSITION %
C Mn Si S P
0.10 max. 0.40-0.60 0.30 Max 0.030 Max 0.030 Max

ALL WELD MECHANICAL PROPERTIES :
YS
(N/mm²)		 UTS
(N/mm²)		 EL %
(l=4d)		 CHARPY “V” NOTCH
IMPACT AT
350-470 450-540 22-30 0°C : 50-80 J

DIMENSION, CURRENT CONDITION & PACKING DATA
Size(mm)
(DXL)		 Size(inch) (DXL) Current Condition (DC-/AC) Amps No. of Pcs./pkt. No. of Pcs./Case
2.00X300 5/ 64”X 12 50-75 250 1000
2.50/ 2.40X350 3/ 32”X14” 60-90 250 1000
3.15/ 3.20X350/ 450 1/ 8”X14/18” 100-130 150 600
4.00X350/ 450 5/ 32” X 14/ 18” 150-180 100 400
5.00X450 3/ 16” X 18” 190-230 60 240
Customer packing on request.
