Help CenterOriginal Mingwei Brand Single Output Type 100 Watt 220V 24v dc Power Supply With Waterproof IP67 Level ce Rohs Approval
Related Products
-
MFW Brand 100w 12 Volt Power Supply in China Wholesale MarketNegotiableMOQ: 50 Units -
Single Output Type Ac220v 50/60hz Input Voltage 12v ac dc Power Supply 50w Waterprrof Switched Mode Power SupplyNegotiableMOQ: 50 Units
-
Hot Sale Mingwei Brand 120W Output Power and 110-230V Input Voltage Waterproof Led Power SupplyNegotiableMOQ: 50 Units
-
Website Hot Selling 30w Waterproof Led Driver 5 Years WarrantyUS$ 5 - 9MOQ: 100 Pieces
-
LKF-12-15 12 Watt 15 VDC Led Power Supplies Mini Led Waterproof Power SupplyNegotiableMOQ: 50 Units
| Model | LKF-100-12 | LKF-100-15 | LKF-100-24 | LKF-100-48 |
| Output | 12V,0~8.5A | 15V,0~6.7A | 24V,0~4.5A | 48V,0~2.0A |
| Error | ±5% | ±5% | ±5% | ±5% |
| Range | 100mV | 150mV | 150mV | 150mV |
| Efficiency | 81% | 81% | 84% | 84% |
| AC input voltage range | 170~264VAC 47~63Hz 240~370VDC | |||
| Input current | 1.2A/230V | |||
| AC inrush current | Cold-start current 30A/230V | |||
| Leakage current | Less than 1mA/240VAC | |||
| DC adjustable range | ±10% rated output voltage | |||
| Over load protection | 115~135% hiccup mode,auto-recovery | |||
| Waterproof level | IP67 | |||
| Setup rise hold up time | 200ms,100ms,30ms | |||
| Withsatand voltage |
I/P-O/P:1.5KVAC 1 minute I/P-FG:1.5KVAC 1 minute O/P-FG;0.5KVAC 1 minute |
|||
| Working temperature | -10 ° C~+60 ° C/20%~90%RH | |||
| Weight/Packing | 1.2KG, 222mm*68mm*43mm | |||
2,Product picture
What we can do :
1. All of our products have proceeded aging test before shipment and we guarantee to use our products safety.
2. Support imprint your logo on products and let your logo shine anywhere.
3. OEM/ODM orders are warmly welcome!
Warranty and Return:
1. All products and accessories have been tested by 3 times before ship out.
2. All products have 2 year warranty ,if there is no man-made problem,we will replace or repair for your freely.
3. We own the best after-sale service ,if any problems happen, our team will do our best to solve for customers.
Founded in 2003, Mingwei Corporation has been recognized as the leading manufacturer of industrial switching power supply and inverters in China. Our self-invested new factory is located in Jiangxi Ruijin, covering an area of 21000m2, and the factory building reach 20000m2. Our company offer products and services ranging from switching power supplies AC/DC&DC/DC standard, PFC, open frame, battery charger, din rail, LED driver to power inverter including mini car inverter, modified sine wave and pure sine wave inverter, battery charger, inverter with charger, domestic inverter, dc to dc converter, solar controller, solar power system, jump starters and other solar related products. Besides, more than 5000 models showing great flexibility. We have R&D department with more than 20 people to insure our product quality, with more than 500 workers guarantee on-time delivery.
Mingwei has been a famous brand in China, increasingly well-known in world market.
WELCOME TO VISIT OUR FACTORY!
TEL:+86-797-2322666 FAX:+ 86-595-2322777
Mob. & whatsapp: 86-13459596085 Winnie wang
Skype: winniewang2919
Note: We are always looking for distribution/ agents in many countries.
