YL Plate Frame Pressure Precision Oil Purifier Machine
(Small, Simple, Cheap)
Feature:
YL Plate Frame Pressure Precision Oil Purifier Machine is suitable to filter various impurities in insulating oil, turbine oil, mechanical oil, hydraulic oil 1-5 or more multi-stage filtration acceptable, filters can be wash / clean to reuse.
Filters choice diversified according to your oil and usage.
It is replacement for the frame-pressurized oil purification machine. It is simple in structure and easy to operate with low price.
YL Plate Frame Pressure Precision Oil Purifier Machine, please search our ZJA, ZJB, JZ, ZJC, JT, DYJC, KYJ… We have full series from low to high for your choice.
Technical Data of YL Plate Frame Pressure Precision Oil Purifier Machine
Parameter |
Type Unit |
YL-50 |
YL-80 |
YL-100 |
YL-150 |
YL-200 |
Flow Rate |
L/min |
50 |
80 |
100 |
150 |
200 |
Motor Power |
KW |
1.1 |
1.5 |
2.2 |
3 |
4.4 |
Inlet/Outlet Diameter |
mm |
32/25 |
38/32 |
44/38 |
48/44 |
64/48 |
Weight |
Kg |
100 |
120 |
150 |
200 |
260 |
Working Pressure |
Mpa |
≤0.5Mpa |
||||
Power Supply |
|
50Hz380V 3-Phase 4-Wire (or as requested) |
||||
Filtering accuracy |
µm |
≤5 |
||||
Delivery lift |
m |
≥15 |
||||
Factory & workshop look
To be shipped
Contact us to get best solution for your oils
Yuneng products list:
1. Insulation Oil Purification Series:
ZJA Ultra-high Transformer / Insulation Oil Filtration Machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)
ZJA High-vacuum Transformer / Insulation Oil Filtration Machine (110KV-500KV project)) (2 stage vacuum)
ZJB Transformer / Insulation Oil Filtration Machine (≤110KV) (one stage vacuum)
ZJ Vacuum Pumping machine (extract vacuum, dry transformer)
GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).
JZ OLTC (on-load tap changer) online Oil Filtration Machine
Quantitative oil injection machine (customized product)
2. Turbine Oil Filtration machine:
JT coalescing dehydration oil filtration machine (dehydration by special filters)
DYJC online turbine oil filtration machine (dehydration by special filters and vacuum system)
ZJC-T vacuum oil filtration machine for turbine oil (dehydration by vacuum system)
3. Lubricating Oil Filtration machine:
ZJC-R vacuum Oil Filtration machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)
ZJC-MOil Filtration machine for OCS. (oil with high viscosity 22-320cst at 40°C)
4. Other kinds of oil filtration machine:
KYJ fire-resistance oil filtration machine (EHC oil)
YL Series Mobile Precision Hydraulic Oil Purifier Oiling Machine (simple, paper filtration)
YL Series Mobile Precision Oil Purifier Oiling Machine (simple, cheap)
5. Waste oil regeneration machine (by chemicals or by high temperature distillation)
YNZSY used oil recycling machine (by chemicals)
YNZSY-LTY used tire oil recycling machine (by chemicals)
Waste oil distillation machine
6. Oil tester/ analyzer:
Dielectric oil breakdown strength tester
Water content tester
Inline Digital Flow Meter and Totalizer
Viscosity analyzer
Flash point analyzer (close cup)
Flash point analyzer (open cup)
Interfacial tension analyzer
Gas chromatograph
