Engine Oil filter machine
(Small, Simple, Cheap)
Feature:
Engine Oil filter machine is suitable to filter various impurities in insulating oil, turbine oil, mechanical oil, hydraulic oil 1-5 or more multi-stage filtration acceptable, filters can be wash / clean to reuse.
Filters choice diversified according to your oil and usage.
Engine Oil filter machine is replacement for the frame-pressurized oil purification machine. It is simple in structure and easy to operate with low price.
For high-quality oil purification machine as vacuum oil filtration machine, please search our ZJA, ZJB, JZ, ZJC, JT, DYJC, KYJ… We have full series from low to high for your choice.
Parameter |
Type Unit |
YL-50 |
YL-80 |
YL-100 |
YL-150 |
YL-200 |
Flow Rate |
L/min |
50 |
80 |
100 |
150 |
200 |
Motor Power |
KW |
1.1 |
1.5 |
2.2 |
3 |
4.4 |
Inlet/Outlet Diameter |
mm |
32/25 |
38/32 |
44/38 |
48/44 |
64/48 |
Weight |
Kg |
100 |
120 |
150 |
200 |
260 |
Working Pressure |
Mpa |
≤0.5Mpa |
||||
Power Supply |
|
50Hz380V 3-Phase 4-Wire (or as requested) |
||||
Filtering accuracy |
µm |
≤5 |
||||
Delivery lift |
m |
≥15 |
||||
Engine Oil filter machine
After-sales Services
One year guarantee for product quality. (People damaged parts are charged).
Lifelong maintenance and spare parts supply.
Free design of fixtures as customers required.
Free training for machines installation and operation of the staffs.
Founded in 1997, Chongqing Yuneng Oil-Filter Manufacturing Co., Ltd located in Chongqing China. Our company is a new and high-tech joint-stock enterprise. We specialize in the R&D, manufacturing, and marketing of oil, water and gas filtering and purification products and complete sets of related equipment. We gather a group of specialized talents with years of working experience and technological development. We can produce 1,000 sets of oil-filtering equipment and purification equipment for other fluids each year. So far we have sold over 15,000 sets of Yuneng-brand oil purifiers. Twenty of our new technologies have received national patents of invention. In 2004 and 2009, our company was rated as “new and high-tech enterprise of Chongqing” twice; there are eleven series products rewarded as “New and High-tech Products of Chongqing”. We have passed I S O 9 0 0 1 quality management certification; some products have passed CE certification, such as YNZSY used oil recycling machine, ZJA double stage vacuum oil purifier. Our products are popular in central South Asia, Middle-East, Europe, America and dozens of countries.In 2009, the latest statistic from Chinese market research center indicated that, among the domestic oil purifier industry, our company’ s market share, competiveness, ranks number one. Yuneng has become a famous brand in the middle-high oil treatment industry. Looking forward to be your supplier and welcome to visit Yuneng.
Factory & workshop look
Canton Fair Exhibition
Contact us to get best solution for your oils
Yuneng products list:
1. Insulation Oil purification machine:
ZJA Ultra-high Transformer / Insulation Oil purification machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)
ZJA High-vacuum Transformer / Insulation Oil purification machine (110KV-500KV project)) (2 stage vacuum)
ZJB Transformer / Insulation Oil purification machine (≤110KV) (one stage vacuum)
ZJ Vacuum Pumping machine (extract vacuum, dry transformer)
GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).
JZ OLTC (on-load tap changer) online Oil purification machine
Quantitative oil injection machine (customized product)
2. Turbine Oil purification machine:
JT coalescing dehydration oil purification machine (dehydration by special filters)
DYJC online turbine oil purification machine (dehydration by special filters and vacuum system)
ZJC-T vacuum oil purification machine for turbine oil (dehydration by vacuum system)
3. Lubricating Oil purification machine:
ZJC-R vacuum Oil purification machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)
ZJC-M Oil purification machine for OCS. (oil with high viscosity 22-320cst at 40°C)
4. Other kinds of oil purification machine:
KYJ fire-resistance oil purification machine (EHC oil)
LY plate-frame pressure oil purification machine (simple, paper filtration)
YL mobile oil purification machine (simple, cheap)
5. Waste oil regeneration machine (by chemicals or by high temperature distillation)
YNZSY used oil purification machine (by chemicals)
YNZSY-LTY used tire oil purification machine (by chemicals)
Waste oil distillation machine
6. Oil tester/ analyzer:
Dielectric oil breakdown strength tester
Water content tester
Inline Digital Flow Meter and Totalizer
Viscosity analyzer
Flash point analyzer (close cup)
Flash point analyzer (open cup)
Interfacial tension analyzer
Gas chromatograph
