Reinforcing Welded Mesh
This mesh is used for reinforcing thin concrete elements such as floor slabs and walls where more strength is required in one direction than the other. Rectangular mesh is manufactured from L grade ribbed wires (D500L) that are welded together with different spacing in each direction to form rectangular apertures.
Rectangular mesh is produced in standard 6m x 2.4m size sheets.
| Ref No. | Unit | Longitudinal Wires mm |
Cross Wires mm | Mass Kg |
| RL1218 (F1218) | Sheet | 11.9@100 | 7.60@200 | 157 |
| RL1118 (F1118) | Sheet | 11.7@100 | 7.60@200 | 131 |
| RL1018 (F1018) | Sheet | 9.5@100 | 7.60@200 | 109 |
| RL918 (F918) | Sheet | 8.6@100 | 7.60@200 | 94 |
| RL818 (F818) | Sheet | 7.6@100 | 7.60@200 | 79 |
| RL718 (F718) | Sheet | 6.75@100 | 7.60@200 | 68 |
Square mesh is manufactured from L grade ribbed wires (D500L) that are welded together with equal spacing in both directions to form square apertures. Square mesh sheets are supplied in 6m x 2.4m with side lap wires to minimize the laps between sheets on large areas.
Products listing
| Ref No. | Unit | Longitudinal Wires mm |
Edge Wires mm | Cross Wires mm | Mass Kg |
| SL81(F81) | Sheet | 7.6@100 | 7.60@100 | 7.60@100 | 105 |
| SL102(F102) | Sheet | 9.5@200 | 6.75@100 | 9.50@200 | 80 |
| SL92(F92) | Sheet | 8.6@200 | 6@100 | 8.60@200 | 66 |
| SL82(F82) | Sheet | 7.6@200 | 5.37@100 | 7.60@200 | 52 |
| SL72(F72) | Sheet | 6.75@200 | 4.77@100 | 6.75@200 | 41 |
| SL62(F62) | Sheet | 6@200 | 4.77@100 | 6@200 | 33 |
| SL52(F52) | Sheet | 4.77@200 | 4.77@100 | 4.77@200 | 21 |
| Ref No. | Unit | Longitudinal Wires mm |
Edge Wires mm | Cross Wires mm | Mass Kg |
| SL102(F102) | Sheet | 9.5@200 | 6.75@100 | 9.50@200 | 80 |
Standard reinforcing bar: standard N grade, 500 MPa deformed reinforcing bar (D500N). Length is available as your request as the reinforcing bar is often supplied processed or fabricated to suit the specific requirements of the project.
Product Listing
| ITEM | Bars per tonne(approx.) | Length(mm) | Metres per tonne(approx.) |
| N10S6 | 270 | 6000 | 1620 |
| N12S6 | 181 | 6000 | 1083 |
| N12S9 | 121 | 9000 | 1083 |
| N12S1 | 91 | 12000 | 1083 |
| N16S6 | 102 | 6000 | 609 |
| N16S9 | 68 | 9000 | 609 |
| N16S12 | 51 | 12000 | 609 |
| N20S6 | 65 | 6000 | 390 |
| N20S9 | 43 | 9000 | 390 |
| N20S12 | 32 | 12000 | 390 |
| N24S9 | 30 | 9000 | 271 |
| N24S12 | 23 | 12000 | 271 |
| N28S12 | 17 | 12000 | 199 |
| N32S12 | 13 | 12000 | 152 |
| N36S12 | 10 | 12000 | 120 |
About us
|
Shijiazhuang Ligeda Commercial and Trading Co., Ltd. located at Shijiazhuang, Hebei Province, China, There is convenient transportation and advantageous location, giving us a quick access to Tianjin Port. We are professional in producing and exporting of diversified iron wire, wire mesh, nail, soap and plastic products, that including galvanized iron wire, black annealed wire, PVC coated wire, common nail, roofing nail, Field Fence, Hexagonal Wire Mesh, welded wire mesh, rebar welded wire mesh, Chain Link Fence, garden border fence, spiral plant support, fence post, Euro fence, Barbed Wire, Razor Barbed Wire, PVC mesh, expanded wire mesh wire mesh fence, soap noodle, laundry soap, toilet soap, detergent, and plastic products etc. Our Products are widely used in Building, Oil, Chemistry, farming, Crafts, and gifts industry, beauty, laundry etc. The Products are in a complete range of specifications. |
Mr Bart, Niu; Foreign Trade Manager;
E-mail: bart@lgdmetal.com Skype: bart niu
Shijiazhuang Ligeda Commercial and Trading Co. Ltd
Tel: (86 311) 66699294; Fax: (86 311) 66699294;
