JZ Series Online On-load Tap Changer Oil Purification Machine for Transformer Maintance
Product's Overview
JZ Series Online On-load Tap Changer Oil Purification Machine for Transformer Maintance regulate the system voltage while the transformer is under energy. They regulate the low and high voltage so they prevent the negative effects of voltage variation.
JZ Series Online On-load Tap Changer Oil Purification Machine for Transformer Maintance do not require maintenance for long time by using online oil filtration machine.
JZ Series Online On-load Tap Changer Oil Purification Machine for Transformer Maintance is mainly used to cycle oil from bypass of the transformer and high voltage switch on line. It can remove moisture and tiny particles to keep oil clean and water content, flash point, breakdown voltage, cleanness of the oil will not go worse.
JZ Series Online On-load Tap Changer Oil Purification Machine for Transformer Maintance Feature:
- Work online with on-load working transformer or high voltage switch
- The filter with high quality material can remove moisture from oil.
- Remove tiny particles by the high quality filters, cleanness up to NAS grade 6.
JZ Series Online On-load Tap Changer Oil Purification Machine for Transformer Maintance Parameters:
Item |
Name of Parameter |
type / unit |
JZ-0.6BF |
|
Technical Parameter of the equipment |
Nominal flow capacity |
L/min |
10 |
|
Working Pressure |
Mpa |
0.5 |
||
Working power |
KW |
(380V-50Hz)3-Phase 4-Wire (380V-50Hz) |
||
Total electric power |
KW |
0.75 |
||
Diameter of inlet/Outlet hose |
DN |
25/25 |
||
Size |
Length |
cm |
53 |
|
Width |
cm |
35 |
||
Height |
cm |
100 |
||
Weight |
Kg |
100 |
||
Oil treatment index |
Filtering Accuracy |
µm |
1 |
|
Cleanness |
NAS level |
≤6 |
||
JZ Series Online On-load Tap Changer Oil Purification Machine for Transformer Maintance Photo for reference:
Founded in 1997, our company Yuneng has been specialized in designing and manufacturing a series of oil purifier for nearly 20 years, such as transformer oil purifier, air pumping unit, dry air generator, turbine oil purifier, lubricating oil purifier, fire-resistance oil purifier, (EHC oil) , waste oil regeneration machine and etc. The proud history makes Yuneng top supplier in oil purification field in China.
We are also the supplier of the Big Transformer Company TBEA in India, hope we could also be your supplier in the near future.
If you are interested in our products, please get back to me for more details.Thank you.
Factory and workshop look
Product's Warranty:
Free design of fixtures as customers required.
On site staff training for installation and operation of the machine is available.
Yuneng products list:
1. Insulation Oil filtration machine:
ZJA Ultra-high Transformer / Insulation Oil filtration machine (1000KV, ±800KV, 750KV, ±660KV project) (2 stage vacuum)
ZJA High-vacuum Transformer / Insulation Oil filtration machine (110KV-500KV project)) (2 stage vacuum)
ZJB Transformer / Insulation Oil filtration machine (≤110KV) (one stage vacuum)
ZJ Vacuum Pumping machine (extract vacuum, dry transformer)
GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).
JZ OLTC (on-load tap changer) On Line Tap Changer Oil Purifier
Quantitative oil injection machine (customized product)
2. Turbine Oil filtration machine:
JT coalescing dehydration oil filtration machine (dehydration by special filters)
DYJC online turbine oil filtration machine (dehydration by special filters and vacuum system)
ZJC-T vacuum oil filtration machine for turbine oil (dehydration by vacuum system)
3. Lubricating Oil filtration machine:
ZJC-R vacuum Oil filtration machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)
ZJC-M Oil filtration machine for OCS. (oil with high viscosity 100-320cst at 40℃)
4. Other kinds of oil filtration machine:
KYJ fire-resistance oil filtration machine (EHC oil)
LY plate-frame pressure oil filtration machine (simple, paper filtration)
YL mobile oil filtration machine (simple, cheap)
5. Waste oil regeneration machine (by chemicals or by high temperature distillation)
YNZSY used oil filtration machine (by chemicals)
YNZSY-LTY used tire oil filtration machine (by chemicals)
Waste oil distillation machine
6. Oil tester/ analyzer:
Dielectric oil breakdown strength tester
Water content tester
Inline Digital Flow Meter and Totalizer
Viscosity analyzer
Flash point analyzer (close cup)
Flash point analyzer (open cup)
Interfacial tension analyzer
Gas chromatograph
