Home > Products > Switch Mode Power Amplifier > 4*1350W Switch Mode Power Supply Amplifier
4*1350W Switch Mode Power Supply Amplifier
Negotiable
/ Piece
1 Piece(Min. Order)
- Huangpu GZ
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | DJG or OEM Brand | |
| Model Number | FP10000Q |
Product Description
The LAB amplifier, FP10000Q, 4 channel switch mode power supply, with stable performance!
| Model | FP10000Q |
| 8ΩStereo Power(RMS) | 1300WX4 |
| 4ΩStereo Power(RMS) | 2350WX4 |
| 2ΩStereo Power(RMS) | 2500WX4 |
| 8ΩBridged Power(RMS) | 4400WX2 |
| 4ΩBridged Power(RMS) | 5000WX2 |
| Frequency Response(+o/-0.3dB, 1W/8Ω ) | 2 Hz - 34.2 kHz |
| THD 20 Hz - 20 kHz for 1 W | < 0.1% |
| THD at 1 kHZ and 1 dB below clipping | < 0.05% |
| Signal-to-Noise Ratio | > 112 dB |
| Channel separation (Crosstalk) at 1 kHz | > 70 dB |
| Input Connectors (per channel) | 3-pin XLR, electronically balanced |
| Output Connectors (per channel) | Speakon Connectors(NEUTRIK) |
| Input Impedance | 20kOhm |
| Common Mode Rejection(CMR) | > 54dB,20HZ to 20kHZ |
| Output Impedance@100HZ | 32mOhm |
| Voltage Peak Limiter Mobe(per ch) | Hard/Soft |
| VPL,selectable per ch.(V) | 150.121.101.83.70.56.47.38V |
| VPL,selectable when bridged (V) | 300.242.202.168.140.112.94.76V |
| Power Requirement | 200-240V~50-60Hz |
| Packing dimension | 580 x 500 x 175mm |
| Net weight(kg) | 13 |
