4*1350W Switch Mode Power Supply Amplifier

Name: 4*1350W Switch Mode Power Supply Amplifier
Brand: DJG or OEM Brand
Price: Negotiable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Product Details

Place of Origin:

Guangdong, China

Brand Name:

DJG or OEM Brand

Model Number:

FP10000Q

The LAB amplifier, FP10000Q, 4 channel switch mode power supply, with stable performance!

Model	FP10000Q
8ΩStereo Power(RMS)	1300WX4
4ΩStereo Power(RMS)	2350WX4
2ΩStereo Power(RMS)	2500WX4
8ΩBridged Power(RMS)	4400WX2
4ΩBridged Power(RMS)	5000WX2
Frequency Response(+o/-0.3dB, 1W/8Ω )	2 Hz - 34.2 kHz
THD 20 Hz - 20 kHz for 1 W	< 0.1%
THD at 1 kHZ and 1 dB below clipping	< 0.05%
Signal-to-Noise Ratio	> 112 dB
Channel separation (Crosstalk) at 1 kHz	> 70 dB
Input Connectors (per channel)	3-pin XLR, electronically balanced
Output Connectors (per channel)	Speakon Connectors(NEUTRIK)
Input Impedance	20kOhm
Common Mode Rejection(CMR)	> 54dB,20HZ to 20kHZ
Output Impedance@100HZ	32mOhm
Voltage Peak Limiter Mobe(per ch)	Hard/Soft
VPL,selectable per ch.(V)	150.121.101.83.70.56.47.38V
VPL,selectable when bridged (V)	300.242.202.168.140.112.94.76V
Power Requirement	200-240V~50-60Hz
Packing dimension	580 x 500 x 175mm
Net weight(kg)	13

Packaging & Shipping
