Flake Ice Machine for Fishery, Supermarket, Concrete Projects, Food Processing 0.75 MT to 50 MT/24 hours on Ammonia or Freon 404We are Indian Manufacturer of Flake Ice Machine & provide complete system with Indigineous refrigeration. We undertake turnkey refrigeration project.
Ice is manufactured in various forms such as flake-ice, tubular ice or crushed ice from ice blocks. The surface area of flake-ice is quite large and covers the product properly. Also being thin, they do not damage the delicate fish skin. The temperatures of the flakers are almost -4 to -5 deg C.
With this excellent characteristics flake ice is always used in the processing industries. It plays an important part in sea food industries which is one of major users of flake ice. It is mandatory that any sea food industries should have a flake ice unit based on the production of the sea food in the ratio of 1: 2 Flake ice is used in Dye making. It also plays an important role in concreting. It is important to keep the concrete mix at low temperature to yield superior concrete and to avoid any cracks in concreting.
Smaller ranges of flake ice units are made suitable for sea water and can be supplied to Deep sea trawlers & small units within ranges of 1 to 2 tons/24 hrs. are also used in super markets.
Flake ice units with capacity ranging from 0.75 tons/24 hours to 50 tons/24 hours. Industrial Refrigeration designs & erects refrigeration system in ammonia or Freon 404A incorporating the flake ice generator.
Aplication Fields:-
- Fishery and aquatic food processing
- Medium and large chain supermarket
- Mine temperature reduction
- Food processing
- Preservation and cooling field application
- Artificial skiing ground
- Medical facilities
- Concrete cooling project
- Dye's chemical industry
Fresh flake ice machine condition:
Electrical require: |
Full electric system complying, With the general international standard |
Standard condition: |
Water inlet temp.16°C,Amibenttemp.16°C |
Application condition: |
Ambient temp.5°C~40°C,water temp. 0.5°C~35°C |
Special condition: |
Ambient temp.-30°C~60°C,water temp.0°C~46°C |
Ice thickness: |
1.5~2.2mm |
Refrigerant: |
R717,R22 ,R404A,R507A |
-Flake ice machine Evaporator Materials selection: | |||
Evaporator |
|
Evaporator |
|
|
|
||
|
|
||
Fresh flake ice machine model and performance parameter :
Model |
Capacity |
Refrigeration |
Evaporating |
Reducer |
Circulating |
Compressor |
Weight |
F035 |
350kg/d |
1645kcal |
-19°C |
0.18kw |
0.025kw |
2HP |
150kg |
F050 |
500kg/d |
2350kcal |
-20°C |
0.18kw |
0.025kw |
3HP |
150kg |
F075 |
750kg/d |
3525kcal |
-20°C |
0.18kw |
0.025kw |
4HP |
150kg |
F10 |
1000kg/d |
4700kcal |
-20°C |
0.18kw |
0.025kw |
4HP |
150kg |
F12 |
1200kg/d |
5640kcal |
-22°C |
0.18kw |
0.025kw |
5HP |
150kg |
F16 |
1600kg/d |
7520kcal |
-22°C |
0.37kw |
0.03kw |
5HP |
150kg |
F20 |
2000kg/d |
9400kcal |
-22°C |
0.37kw |
0.03kw |
6HP |
150kg |
F25 |
2500kg/d |
1175kcal |
-22°C |
0.37kw |
0.03kw |
8HP |
150kg |
Features:-
- Scientific design and many years of engineering experience
- Safety and sanitation
- High reliability and low breakdown rate
- High efficiency and energy saving
- Simple maintenance and convenient moving
- Great adaptability and stable quality
- Outstanding electric control system
Aplication Fields:-
- Fishery and aquatic food processing
- Medium and large chain supermarket
- Mine temperature reduction
- Food processing
- Preservation and cooling field application
- Artificial skiing ground
- Medical facilities
- Concrete cooling project
- Dye's chemical industry
