INTRODUCTION:
Our notching machine is a kid of special cutting equipment, used in sheet metal processing edge or corner of the triangle gap, which is widely used in electrical appliances,
metal cabinet body, ventilation equipment, kitchen equipment, decorative materials, such as sheet metal processing field. The hydraulic system on our machine is reliable,
professional manufacturer of custom tanks, the use of domestic brandname long source pumps, and Rexroth valve. Professional tools, long life, suitable for
cutting carbon steel and stainless steel plate.
Fixed Hydraulic & Adjustable Angle Notching Machine Corner Notching Machine
TECHNICAL DATA
| Model | 4 x 200 | 6 x 220 | |
| Cutting ttickness | Mild steel | 0.5-4mm | 0.5-6mm |
| Stainless Steel | 0.5-2.0mm | 0.5-3mm | |
| Cutting Length | 200mm | 220mm | |
| Cutting Angle | 40°-135° | 30°-140° | |
| Stroke per Minute | 35+ | 30+ | |
| worktable height | 850mm | 850mm | |
| Dimension (L x W x H) | 890 X 870 X 1080mm | 950 X 1150 X 970mm | |
| Weight | 860Kgs | 970Kgs | |
ADVANTAGES:
1.Strong and simple construction
2.NO maintenance
3.Fixed blades clearance for any thickness and material
4.Corrosion-resistant components
5.High quality components
6.Eco-friendly materials
7.Manufactured according to european safety rules, CE
8.Fast and easily adjustable angles by hand wheels.
