LED Constant Current Driver 9w
US$ 3 - 4
MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GWP
Model Number:
SPS-2A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LED Constant Current Driver 15wUS$ 3 - 4MOQ: 20 Pieces -
100-277VAC Input 60W Led Power Supply Led DriverUS$ 10 - 20MOQ: 100 Pieces
-
UL&CE&ROHS Approved 60W Led Power Supply Led DriverUS$ 10 - 20MOQ: 100 Pieces
-
Dimmable 0-10V UL 40W Led Power SupplyUS$ 10 - 20MOQ: 100 Pieces
-
UL 40W Led Power Supply Led Driver for All Kinds Led LightsUS$ 10 - 20MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
GWP
Model Number
SPS-2A
Specifications
LED constant current driver 9w1. UL&cUL number E343521
2. Three years warranty
3. Input voltage: 100-277V
200-1200mA
LED constant current driver 15w
1. UL&cUL number E343521
2. Three years warranty
3. Input voltage: 100-277VAC
120-1200mA MAX
.E343521 UL/CUL Class 2
| General Specification | |||||||||
| Item | SPS-2A01505011H | SPS-2A01505012H | SPS-2A02405011L | SPS-2A04005011L | SPS- 2A04005011LD |
SPS- 2A06005011H |
|||
| AC input Voltage range: |
100-277VAC | ||||||||
| Input current: | 0.25A | 0.25A | 0.33A | 0.56A | 0.56A | 0.9A | |||
| Efficiency: | >80% | ||||||||
| Current adjustment range: |
75%-103% rated output current adjustable by internal potential meter |
||||||||
| Power factor | >0.95 | ||||||||
| Output Voltage: | 27-38VDC | 15-27VDC | 20-40VDC | 20-40VDC | 20-40VDC | 24-38VDC | |||
| Output Current: | 120-400mA | 0-560mA | 400-650mA | 650-1000mA | 1A Max 0-10V Dimmable |
1100-1600mA | |||
| Out Power: | 5-15W | 15W | 24W | 40W | 40W | 60W | |||
| Operating temperature: |
-25°C~+40°C | ||||||||
| Working temperature | -30°C~+60°C | ||||||||
| Safety standards | ul/cul :ul8750,ul1310 CAN/CSA C22.2 NO.223 EN61347-1,EN61347-2-13 | ||||||||
| EMC Standards | EN 55015:2006+A1:2007+A2:2009 EN61547:2009 EN61000-3-2:2006+A1:2009+A2:2009 EN 61000-3-3:2008 EN61347-1:2008 EN61347-2-13:2006 |
||||||||
| Connection | input | UL rated, 18AGWx2c 20cm | |||||||
| output | UL rated, 18AGWx2c 20cm male-female connector | ||||||||
| Dimension(LxWxH)(mm) | 88*39*22.5MM | 127*43*22mm | 142*45*30mm 100pcs/Carton | ||||||
| Packing | Carton | ||||||||
==========================================================================================================
| General Specification | ||||||||
| Model No. | SPS- A200905011 |
SPS- A201505011 |
SPS- A201805011 |
SPS- A202405011 |
SPS- A203605011 |
|||
| AC input Voltage range: |
100-277VAC | |||||||
| Input current: | 0.15A | 0.20A | 0.3A | 0.35A | 0.5A | |||
| Efficiency: | >80% | |||||||
| Current adjustment range: |
75%-103% rated output current adjustable by internal potential meter |
|||||||
| Power factor | >0.95 | |||||||
| Output Voltage: | 27-38VDC | |||||||
| Output Current: | 220mA | 360mA | 440mA | 560mA | 1A Max | |||
| Out Power: | 9W | 15W | 18W | 24W | 36W | |||
| Operating temperature: |
-25°C~+40°C | |||||||
| Working temperature | -30°C~+60°C | |||||||
| Safety standards | ul/cul :ul8750,ul1310 CAN/CSA C22.2 NO.223 EN61347-1,EN61347-2-13 | |||||||
| EMC Standards | EN 55015:2006+A1:2007+A2:2009 EN61547:2009 EN61000-3-2:2006+A1:2009+A2:2009 EN 61000-3-3:2008 EN61347-1:2008 EN61347-2-13:2006 |
|||||||
| Connection | input | UL rated, 18AGWx2c 20cm | ||||||
| output | UL rated, 18AGWx2c 20cm male-female connector | |||||||
| Dimension(LxWxH)(mm) | 127*43*22mm | 142*45*30mm | ||||||
| Packing | 33x33x34cm 100pcs/ctn | 33x33x42cm 100pcs/ctn | ||||||
.
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
LED constant current driver 15w
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
LED constant current driver 15w
-----------------------------------------------------------------------------------------------------------------------------------------------------------------
LED constant current driver 15w
