Type Wireless
Application Enterprise
Function Firewall, QoS, VPN
LAN Ports 16
WAN Ports 1
Certification ce tuv gs
Brand Name OEM
Model Number H100SR
Place of Origin Guangdong, China
Mini Wifi AP Recap

Mini WiFi AP is designed to extend the original WiFi signal coverage, while it can ensure the security of the wireless signal, at the edges of the original WiFi hot spot signal coverage, the WiFi AP is able to receive weak WiFi signal, and then zoom in to the normal, safe strength, and after optimization, error correction processing, to achieve signal coverage distance doubled extension under safe.



1. Support 802.11n WiFi transmission protocol, 150Mbps rate of transmission.

2. WiFi intelligent bridge function, Wireless switch wired, wired switch wireless, intelligent switch.

3. WiFi intelligent repeater mode, WiFi hotspots scan automatically and hotspot memory function.

4. Support WPA-PSK/WPA2-PSK 64/128/WEP security mechanism.

5. Signal effect range: 100m



Mini WiFi AP Tech Data
Hardware
Main Chipset MT7620A
RAM DDR2 128MB (MAX DDR2 256MB)
SPI Flash 16MB  (MAX 16MB)
Protocol IEEE 802.11n
Rt Power 802.11n   15dBm±2dBm
Reception Sensitivity 802.11n: -68dBm@10% PER
Work Channel 2.4GHz choose :1-13
Wireless Rate Max 150Mbps(depends on the 11AC mode)
Work Frequency 2.4GHz
Antenna /
Interface 1 PCI-E slot

  10/100M WAN port(Auto MDI/MDIX)
  10/100M LAN port(Auto MDI/MDIX)
Led Power,PCIE mode ,2.4G,WAN,LAN
Button Reset/WPS
Max Power Consumption < 3.5W
Power DC5V, 0.7A
Dimension(L*W*H) 102*60*20MM
Software
Wan Type PPPoE,Dynamic IP, Static IP











Work Mode

 AP;
Router;
Dhcp Server, Client, DHCP Client List, Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Firewall Security Dos, SPI Firewall
IP Address Filter/MAC Address Filter/ Domain Filter
IP and MAC Address Binding
Ddns Support
Vpn Pass-Through PPTP, L2TP, IPSec (ESP Head)
Band Ctrl Support
Static Router Support
System Log Support
Other Function Mac clone
NTP Synchronize
Web firmware upgrade
Others
Work Environments Operating Temperature:0℃ ~ 40℃
Storage Temperature:-40℃~ 70℃
Operating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Adapter 12V 1A
Other Accessories
Advanced

Primary competitive advantages:

1. Experienced staff

2. Green product

3. Guarantee and warranty

4. Authority approval

5. Product features

6. Product performance

7. Multi payment terms

8. Fast delivery time

9. Cascading quality inspect

10. Better after sales service



Main export markets:

EU, Asia, US, AF, AU



Payment and Delivery:

Payment: T/T, L/C, D/P, D/A, Western Union, Money Gran
Unit Size: receiver 151*29.2*76, transmitter 81*58*121
Delivery: 3000PCS/15 DAYS
Packing:  standard export carton

After sales services:

Product theory function time 10 years.

All items warranty 1 year.

Us

Eco-Logic Manufacturing Limited is professional in the green products such as energy meter, timer, remote switch etc for 8 years, we have a factory in Guangdong China with 10,000 square meters and 350+ members, monthly capacity of 100K. Besides energy business, we also provide other services such as injection, screen printing, assemble and more.



For better services, it is a practice to have a 2-week professional training for our new comers to ensure the high quality product maintenance.
