UHT Milk Sterilizer Machine

wooden case and plastic bag

Specifications

used to pasteurizer dairy milk such as
1.fresh cow milk
2. soy milk



application

technical parameter

Model	BS-BS-1	BS-BS-2	BS-BS-3	BS-BS-4	BS-BS-5	BS-BS-10
Product capacity T/h	1	2	3	4	5	10
Heeat exchanging area (m2)	12	15	20	25	28	52
Sterilizing temperature(°C)	85-95	85-95	85-95	85-95	85-95	85-95
Warmkeeping timeS	25	25	25	25	25	25

 2.

1. Usage: Pipe sterilizer can take hot process on the dairy production, liquid foods beverage, concentrate jam, biology, medicine etc. sterilizer of other model.

2. Main structure: Material tanks, sterilizer tank, material pump, exheater, hot water cross occur, controller etc.

3.Working principle: pre-sterilizing, sterilizing for the pipe which material will touch, use the hot water cycle in the pipe, more than 20 min, then lower the pipe temp., starting sterilizing for the material. The material which had disposal to the material tank, use the pump sending to pipe heat exchanger. Then put the material into heater pipe and sterilizing according to require time, and after sterilizing to the keeping pipe, then into the cooling pipe and sending to the filling machine.

application

2.. horizontal sterilized

1.  killing germs with circulating hot bath

2.  the pot is heated ahead of time, which can save time and improve efficiency.

3.  the hot water can be reused, which save water, energy, labor ,materials and time consumption

4.  protection system will make alarm calls automatically when the temperature, the pressure, the water level, or any other kinds of error occur.
