Best Offer of Automatic Wooden Handle Forming Machine
- 100 Set / Sets per Month
- Tianjin
- T/T Credit Card
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
- Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
- Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
- Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
- Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
Place of Origin: | Henan, China | Brand Name: | REPHALE | Model Number: | SBJ |
Product Description
Specifications
-High efficiency, three times as traditional machines-HIgh qualification rate
-High working efficiency
I Brief Introduction
Our automatic wooden handle forming machine changes the traditional single blade skewering methods of the old machines, Our automatic wooden handle forming machine applys two blades to form wooden handle. This will save the processing of turning sides of wooden handle when operating the machine. Moulding plate will be fixed only by fastening two screws. The ratio of sizes of moulding plate and wooden handle is 1:1. The wooden handle process is very easy. Feeding is continuous. Feeding process is in front while output is in the behind. Forming of handles is automatic, which saves process of loading and unloading of brush. As a result, all this will save working time.
II Performance and Features
1.Safe performance
Blades of automatic wooden handle forming machine are inside, namely being installed inside the machine. It is impossible that workers' fingers can touch blades. Therefore, there is no fingers hurting and broken events. 2. Easy to operate
Speeding of handle forming can be adjusted but not be decided by skill of workers. Workers just need to put handles on moulding plate and no other requirement is needed.
3.Practical Performance
We can design different models of automatic wooden handle forming machine according to customers' different wood. The general model is suit to common wood with good tenacity and wood lines being in same direction with blades. Special I model is particularly used to process wood with brittleness and wood lines being not straight. The forming process is that push blades to neck parts and then pull blades reversely from backside in case that it will destroy wood. This special model is suit to process birch.
III Parameters
Model | Power (KW) | Capacity (piece) | Specification of wooden handle | Dimension (m) | Weight(kg) |
MBJ | 4.4 | 8000-9000 | Wood handle (5 inches below) | 1.1*0.9*1.5 | 300kg |
IV More detail Picture about Automatic Wooden Handle Forming Machine
In case of wanting to buy our products, please feel free to contact:
Contact Us
- Zhengzhou Rephale Machinery Co., Ltd.
- Contact nameSusan Wang
- Phone0086-371-67670501
- AddressNo.238 Qinling Road Zhengzhou,Henan
