SGS hot sale small 12v 24byj48 gear stepper motor
Main Performance of SGS hot sale small 12v 24byj48 gear stepper motor
Diameter: 24 mm
Step Angle: 5.625°
Voltage: 5V, customized.
Phase: 4
Excitation: 1-2
Parameter of SGS hot sale small 12v 24byj48 gear stepper motor
Driving Voltage |
5±10% V |
Phase |
4 Phase |
Lead Wire |
5 |
Excitation |
1-2 |
Reduction |
1/64 |
Step Angle |
5.625° |
Resistance |
21±10% Ω |
Pull In Frequency |
500 Hz |
Pull Out Frequency |
1000 Hz |
Pull In Torque |
90 mN.m |
Detent Torque |
90 mN.m |
Insulation Resistance |
50 MΩ |
Dielectric Strength |
500/600 VAC(min) |
Friction Torque |
1.2-1.5 Kgf.cm |
Insulation Grade |
B |
Temperature Rise |
60 K |
Weight |
27 g |
Noise |
40 dBmax |
All parameter can be customized according to your actural demand, for detailed information please contact me or leave a message.
Drawing of 24BYJ48-033
Application of 24BYJ48-033
