Help CenterSR868C8 Solar Controller ,SP106 Work Station Solar System Controller, Solar Water Heater Controller(manufacture and Factory )
Related Products
-
Roundness Solar Water Storage Tank for Large Project (in Mexico Hotel )US$ 100 - 1,500MOQ: 1 Unit -
Non-pressure System Solar Water Heater Intelligent Controller(factory )NegotiableMOQ: 1 Unit
-
Square Solar Water Storage Tank for Large Project (Manufacture)US$ 100 - 1,500MOQ: 1 Unit
-
SR868C8 Solar Controller ,solar System Controller, Solar Water Heater Controller(manufacture)US$ 15 - 70MOQ: 1 Piece
-
Solar Water Storage Tank for Large Project (USA Hotel ),solar Storage Tank,US$ 100 - 1,500MOQ: 1 Unit
SR868C8 Solar Water Heater Controller, solar system controller
2.Self power consumption: <3W
3.Measuring accuracy of temperature: ±2degree
4.Temperature range of measurement: 0degree to 120degree
5.Power of temperature difference controlled circulation pump≤600W
6.Power of time controlled circulation pump≤600W
7.Power of auxiliary electrical booster ≤2000W
1.Time heating
2.Temperature difference control
3.Collector emergency shutdown
4.Collector cooling function
5.Anti-Legionella function
llector low temperature protection
llector frost protection
8. Maximum temperature of tank(1*storage tank)
9. Tank re-cooling function
10.Celsius and Fahrenheit temperature exchange
11. Temperature controlled hot water circulation pump
12. High temperature by-pass function(Collector cooling down)
13. Manual mode(for 4 outputs:P1,P2,R1,H1)
14. Password setting
15. Recovery to factory setting
16.Holiday function
17.Manual heating
18.Temperature query function
19.Memory Protection
20.Anti-dry heating Protection
21.Screen protection
22.Trouble shooting
23.Trouble protection
24.Trouble checking.
25.nMIN Solar circulation pump speed adjusting (RPM speed controlling)(Only available on SR868C8Q)
26.OHQM Thermal energy measuring (Only available on SR868C8Q)
27.INTV Pump interval function (Only available on SR868C8Q)
Main including:
1. Compact solar water heaters system controllers
2. Split solar water heating system controllers
3. Solar swimming pool system controllers
4. Split solar water heating system working stations
5. MPPT controllers
6. Solar charger controllers
7. Light controllers
8. Copper fittings
9. Copper valve
