Help CenterSpecialized Access Control Power Supply Box 12V 3A PY-PS5
Related Products
-
Access Control 12V Power Supply With Battery Backup PY-PS2-3US$ 12 - 19MOQ: 5 Pieces -
Access Control Power Supply 12V PY-PS1-3US$ 8 - 10MOQ: 1 Piece
-
Dampproof Design 12V/3A Power Supply Used for Access Control PY-PS1-3US$ 8.5 - 13MOQ: 1 Piece
-
12V10A CCTV Switch Power Supply 120W PY-12V10AUS$ 7.2 - 9.9MOQ: 1 Piece
-
12V 20A 18-Way 25W Power Supply Box PY-25WUS$ 30 - 35MOQ: 10 Units
Specifications
Output Voltage:12VDCPower:30W
Charge discharge function:Yes
Color of case:Black
Specialized Access Control Power Supply box 12V 3A PY-PS5
Description:
The power supply can support the controller, reader and one to two additional electronic locks.It has charge-discharge function. If connect with standard 12V 7AH storage battery, when power cut, it can ensure the door access control system work properly.
Specifications:
| Unit Size | 273mm*228mm*65mm |
| Unit Packing Way | BOX |
FEATURES |
|
| power transformer |
30-50W High power transformer ,with higher efficiency, big output power for work with 2-4 card readers +1 controller+4 pcs Electronic Locks or 3 pcs magnetic lock with 280Kg |
| thermal exhaust |
With standard thermal exhaust design. All metal design, good anti-interference and thermal exhaust. |
| the cover |
Cover can be removed and fitted buckle, with standard PVC pipe, and 5 Gourd-shaped hooks inside of case. |
| the fuse |
Power has 5A fuse in front-end and back-end, with protective circuit in case damage by short-circuit. And convenient to change new fuse the corresponding fuse has prompted lights. |
| inside of case |
Inside of case with Ground connection point design for lightning protection, anti-static and anti-Surge |
| wiring space | Sufficient space for wiring, Pull out terminal blocks. |
|
battery depletion protection |
Protection for battery depletion, If the rechargeable battery exhausted, the battery will damage and obsolescence,If without the protection for exhaust ,will result in a critical state, invalid for read card ,power locked,user will locked up until the power supply runs out or reset. |
| charge |
With Charge and discharge function, can circumscribed battery with 7AH 12VDC to support 3-5 hours work with 1pc electronic lock ,1 pc card reader,1 pc controller . |
| PARAMETERS | |
| Power | 30-60W |
| Output Voltage | 12VDC(11-14V) |
| Current Rating | 3A |
|
Storage battery Specification |
7AH 12VD C |
|
Storage battery Protection Voltage |
9V |
