1,QD model overhead travelling crane with hook is mainly composed of bridge, running gear of crane, trolley and electrical device ,etc. It is divided into two working classes; A5 and A6 according to the use grade and load-up condition.
2, There are three kinds of method for entering the platform of cab: from the side, from the end and from the top. The figure is the side entrance; arrowhead A show the end entrance; the top entrance is at the place there is no door.
3, The figure shows that the cab is mounted at the left end .
4, Safe slide wire or angle iron can be used for electric conduction of the crane; it can be either at the opposite side of the cab(same as the figure) or at the same side of the cab.
5, Operation of the crane shall be finished in the cab completely.
Drawing:
Xinxiang City, Henan Zhongyuan Hoisting Machinery Plant Co., Ltd. was established in 1985, it's crane manufacturer of the Ministry of Machinery Industry of China. Our Co.,Ltd is national grade two measure qualified department and we pass the ISO9001 international certification in 1999. The products are marketing in various industries of mine, building material, chemistry, electric power , communications, railway, olifield and port, etc. We have complete set CAD computer aided design systerm and large datebase; it is capable to undertake the design, manufacture and product development of various special purpose products and non-standard products.
Business Scope: LD 1-20t electric single-beam hoisting series products;5-600t general purpose bridge, gantry, metallurgy, upper rotation, lower-rotation electromagnetic suspend, insulation,grab bucket, explosion prevention crane series products LH3-100t electric block dual-beam series products; MH5-32t electric block gantry crane series products; 0.5-40t CD1 wire rope electric block series products series products; HS1 0.5-20t manual block series products; 0.5-10t ring-chain electric block serious products, 0.5-40t bend electric block series products; assemble and unassembled bridge , shipbuilding gantry crane, bridging crane, casting suspend and water and electricity large tonnage crane.
| Light crane A1 to A4 |
| Single girder bridge crane | 0.5 t / 1 t / 2 t / 3 t / 5 tons / 10 tons / 16 tons / 20 tons |
| Crane A5 to A6 |
| Single girder bridge crane | 5 tons / 10 tons / 16 tons / 20 tons / 30 tons |
| Single girder gantry crane | 5 tons / 10 tons / 16 tons / 20 tons / 30 tons |
| Double girder bridge crane | 5 tons / 10 tons / 16 tons / 20 tons / 32 tons / 50 tons |
| Double girder gantry machine | 5 tons to 150 tons |
| Heavy crane A7 to A9 |
| Double girder bridge crane | 5 tons to 500 tons |
| Single-beam gantry crane | 10 tons / 15 tons / 20 tons / 32 tons / 40 tons / 50 tons |
| Double girder gantry crane | 5 tons to 200 tons |
Your first choice for high efficiency work
1. 30years crane manufacture experience—We set up at 1985.
2. International standard indoor warehouse— we can delivery on time even bad weather
3. Famous trademark “Yuqi” , and we also have many certificate of patent.
4. Many senior crane design engineers, with fast and professional design.
5. Crane installation and crane commissioning service supply
Different type and special requirement can be customized.
Packing:
1. Electrical parts and hoist are packed by strong plywood box or as client demand.
2. Main beam, end beam, platform railing and others are packed in plastic woven cloth, to prevent corrosion in seawater.
