Air pressure dp transmitter with output 4-20mA
Based on piezo-resistive silicon technology, QWB301 differential pressure dp transmitter uses silicon differential pressure sensors
with stainless steel isolated diaphragm as measuring elements. Made from 316L stainless steel and designed of rigid and robust
construction, UPB5 differential pressure transmitter is suitable for application in harsh environment and measurement with corrosive pressure media.
This product has widely been used for measurement of differential pressure of pipeline fluids in petroleum industry, chemical industry, electric power hydrology etc.
Features:
*Reliable performance, good long term stability*Good static pressure, good ability of anti-impact and overload pressure*Strong reversed polarity protection and current limiting protection*Light weight, easy installation*Integrated stainless steel construction design, small volume
Specifications
| Range | ±(50Pa~200Pa~1KPa~10KPa ~100KPa) |
| High pressure | three times the range values |
| Comprehensive accuracy | 0.5%FS, 1.0%FS |
| Output signal | 4~ 20mA ( two wire system ), 0~5V, 1~5V, 0~10V ( three wire system ) |
| Power supply voltage | 24DCV ( 9 ~ 36DCV) |
| Medium temperature | -20 °C ~ 85 °C |
| Environment temperature | room temperature ( -20 ~ 85°C) |
| Load resistance | current output type: maximum 800 Ω; voltage output type: larger than 50KΩ |
| Insulation resistance | larger than 2000MΩ ( 100VDC) |
| Sealed class | IP65 |
| Long term stability | 0.1%FS/year |
| Influence of vibration | within mechanical vibration frequency: 20Hz ~ 1000Hz, output variation is less than 0.1%FS |
| Electrical interface | The lead wire |
Mechanical connection | M10 ×1,custom made is available. |
We are a professional high tech enterprise that engaged in the development, sales and customized service of
Pressure sensors
Pressure transmitters,
Temperature sensors
Temperature transmitters,
Flow meters,
level measuring instruments,
Calibration instruments
Pressure gauges etc.
They are widely used inaerospace, automobile petroleum, chemical, metallurgy, Paper-making,
drugs manufacturing, electric power, food, medicine, railroad and water conservation etc industries
Any inquiry, contact us freely.
