Help Center1.25G Duplex Optical Module 80km Compliant With RoHS Specification
Related Products
Specifications
1.25G duplex optical module1.Hot -pluggable SFP Footprint
2.ROHS DDM available
3.LC fiber interface
4.CE,FCC,ROHS ect
SFP Fast Gigabit Ethernet Transceiver
The IEEE 802.3z standard includes 1000BASE-SX for transmission over multi-mode fiber, 1000BASE-LX for transmission over single-mode fiber, 100BASE-FX is a version of Fast Ethernet over optical fiber. It uses a 1300 nm near-infrared (NIR) light wavelength transmitted via two strands of optical fiber, one for receive(RX) and the other for transmit(TX), 100BASE-SX is a version of Fast Ethernet over optical fiber. It uses two strands of multi-mode optical fiber for receive and transmit. Eoptolink is produce complete range for FE and GE optical fiber transceivers.
Product Feature
Operating Temperature :0°C-70°C or -40°C-85°C
1310//1490/1550nm FP or DFB LD transmission
Transmission distance:120km max
LC fiber interface
Voltage:+3.3V
Compliant with ITU-T G.957 G.958 specification
Compliant with Telcordia(Bellcore)GR-468-CORE specification
Compliant with RoHS specification
Standard Application
ATM SDH PDH SONET Network
Data Communication Network
Telecom Communication Network
If you cannot find the model you are looking for, please, contact with us.
P/N |
Data Rate |
Distance |
LD |
PD |
DDMI |
OFSS-8503-02C(D) |
155Mbps |
2km |
850nm VCSEL |
PIN |
N(Y) |
OFSS-1303-02C(D) |
155Mbps |
2KM |
1310nm FP(LED) |
PIN |
N(Y) |
OFSS-1303-20x(D) |
155Mbps |
20KM |
1310nm FP |
PIN |
N(Y) |
OFSS-1303-40x(D) |
155Mbps |
40KM |
1310nm FP |
PIN |
N(Y) |
OFSS-1503-80x(D) |
155Mbps |
80KM |
1550nm DFB |
PIN |
N(Y) |
OFSS-1503-120CD |
155Mbps |
120km |
1550nm DFB |
PIN |
Y |
OFSS-1503-150CD |
155Mbps |
150km |
1550nm DFB |
APD |
Y |
OFSS-8512-05x(D) |
1.25Gbps |
550m |
850nm VCSEL |
PIN |
N(Y) |
OFSS-1312-20x(D) |
1.25Gbps |
20km |
1310nm FP |
PIN |
N(Y) |
OFSS-1312-40x(D) |
1.25Gbps |
40km |
1310nm DFB |
PIN |
N(Y) |
OFSS-1512-80x(D) |
1.25Gbps |
80km |
1550nm DFB |
PIN |
N(Y) |
OFSS-1512-120xD |
1.25Gbps |
120km |
1550nm DFB |
APD |
Y |
OFSS-1312-30x(D) |
1.25Gbps |
30km |
1310nm FP |
PIN |
N(Y) |
OFSS-1512-40x(D) |
1.25Gbps |
40km |
1550nm DFB |
PIN |
N(Y) |
OFSS-8521-03x(D) |
2.125Gbps |
300m |
850nm VCSEL |
PIN |
N(Y) |
OFSS-1321-10x(D) |
2.125Gbps |
10km |
1310nm FP |
PIN |
N(Y) |
OFSS-1321-20x(D) |
2.125Gbps |
20km |
1310nm DFB |
PIN |
N(Y) |
OFSS-1321-40xD |
2.125Gbps |
40km |
1310nm DFB |
APD |
Y |
OFSS-1521-80xD |
2.125Gbps |
80km |
1550nm DFB |
APD |
Y |
OFSS-8525-03x(D) |
2.5Gbps |
300m |
850nm VCSEL |
PIN |
N(Y) |
OFSS-1325-2x(D) |
2.5Gbps |
2km |
1310nm FP |
PIN |
N(Y) |
OFSS-1325-20x(D) |
2.5Gbps |
20km |
1310nm DFB |
PIN |
N(Y) |
OFSS-1325-404xD |
2.5Gbps |
40km |
1310nm DFB |
APD |
Y |
OFSS-1525-20x(D) |
2.5Gbps |
20km |
1550nm DFB |
PIN |
N(Y) |
OFSS-1525-40x(D) |
2.488Gbps |
40km |
1550nm DFB |
PIN |
N(Y) |
OFSS-1525-80xD |
2.5Gbps |
80km |
1550nm DFB |
APD |
Y |
OFSS-1525-120CD |
2.5Gbps |
120km |
1550nm DFB |
APD |
Y |
