Specifications
pliant with Cisco,HP.3COM,Juniper2.DDM function available
3.good performance and competitive price
4.3~5days
5.CE,ROHS
10Gb/s BIDI SFP+ Transcei PRODUCT FEATURES
FEATURES
Up to 10.7Gbps Data Links
Single Mode LC Receptacle Bi-directional Transceiver
Up to 20km transmission on SMF
Power dissipation<1.0W
1270nm DFB laser and 1330nm PIN receiver
wire interface with integrated Digital Diagnostic monitoring
EEPROM with Serial ID Functionality
Compliant with FC_PI_4 REV 7.0
Compliant with SFP+ MSA with duplex LC connector
Single + 3.3V Power Supply and LVTTL Logic
Operating case temperature:0~+70ºC
APPLICATIONS
10GBASE-BX at 10.3125 Gb/s
10GBASE-BX at 9.953 Gb/s
1000 Base-LX Ethernet
8XFC at 8.5Gbps
4XFC at 4.25Gpbs
2XFC at 2.125Gpbs
1xFC at 1.0625Gbps
PRODUCT DESCRIPTION
OFSBP-2710-20D is hot pluggable 3.3V Small-Form-Factor transceiver module . It designed expressly for high-speed communication applications that require rates up to 10.7Gb/s, it designed to be compliant with SFF-8472 SFP+ MSA. The module data link up to 20KM in 9/125um single mode fiber.
The optical output can be disabled by a LVTTL logic high-level input of Tx Disable. Tx Fault is provided to indicate that degradation of the laser. Loss of signal(LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner
1. Absolute Maximum Ratings
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Unit |
Note |
Storage Temperature |
Ts |
-40 |
- |
85 |
ºC |
|
Storage Ambient Humidity |
HA |
5 |
- |
95 |
% |
|
Operating Relative Humidity |
RH |
- |
- |
85 |
% |
|
Power Supply Voltage |
VCC |
-0.3 |
- |
4 |
V |
|
Signal Input Voltage |
|
Vcc-0.3 |
- |
Vcc+0.3 |
V |
|
2. Recommended Operating Conditions
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Unit |
Note |
Ambient Operating Temperature |
TA |
0 |
- |
70 |
ºC |
Without air flow |
Power Supply Voltage |
VCC |
3.14 |
3.3 |
3.47 |
V |
|
Power Supply Current |
ICC |
- |
- |
300 |
mA |
|
Data Rate |
BR |
|
10.3125 |
|
Gbps |
|
Transmission Distance |
TD |
|
- |
20 |
km |
Note (1) |
Coupled fiber |
Single mode fiber |
ITU-T G.652 |
||||
Note (1). Measured with SMF
