Fiber Optical Splice Closure

Name: Fiber Optical Splice Closure
Brand: Optfocus
SKU: 107910261
Availability: InStock

Negotiable MOQ: 10 Pairs (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Optfocus

Model Number:

OFS-FTH-502

Shenzhen Optfocus Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Optfocus

Model Number OFS-FTH-502

Specifications

Applications
Suitable for bunchy fibers
Aerial,underground,wall-mounting,hand hole-mounting and duct-mounting

Fiber Optical splice closure

Features:

l Convenient to increase or reduce trays/ cassette for capacity requirement

l Improved reinforce rebar on the body of closure make excellent performance under impact, pulling, tension etc

l 3 fixing item/designs to prevent fiber cable from external effect

l Spacious place for storing and maintenance

l adapter plug-in fits a variety of adapters such as SC, FC, LC (duplex).

l Can be used from 40 °C to +65°C temperature range

l Integrated seal, air tight and water proof, flame-retarded

l Suitable for aerial, wall, underground duct or direct burial applications

Applications

l Suitable for bunchy fibers

l Aerial,underground,wall-mounting,hand hole-mounting and duct-mounting

l It's especially applicable to FTTH optical fiber distribution

OFS-FTH-502 Fiber Optic Splice Closure Datasheet

Model No.	Size (mm) L×W×H	Core capacity	Cable Ports (max)	Max diameter of cable (mm)	Adapter and holes of Front Panel
OFS-FTH-502	323x202x86	48 cores	6	2×Ø20 2×Ø16 2×Ø13	FC adapters:6PCS
					SC adapters:8PCS
					ST adapters:8PCS
					LC adapters:8PCS

Remarks:

Installation accessories provided: one set of elastic seal fitting, seal tape, insulation tape, 2 pieces of special wrenches, abrasive cloth, earthing wire, nylon ties, labeling paper, measuring paper and desiccant.

Accessories by customers’ selection: earthing device, buffer pipe for bunchy fiber, pressure testing valve, adapter panel, adapter, pigtail, patchcord, wall-mounting bracket and pole mounting bracket.
