FS-SPRJ 45/4 network surge protector
1.Single Channel Network Surge Protector
Model |
FS-SPRJ45/4 |
Product Name |
RJ 45 network surge protector |
Function |
RJ 45-100M Ethernet surge protection |
Applied Dices |
Terminal PC network card and other network equipments interface |
Connection Type |
RJ 45 |
Nominal Operating Voltage (Un) |
5V |
Max Continuous Running Voltage (Uc) |
8V |
Limited Voltage |
15V |
Rated Load Current ( IL) |
500mA |
Nominal Discharge Current {In (8/20us)} |
5KA |
Max Discharge Current {(Imax (8/20us) } |
10KA |
Response Time |
≤1ns |
Max Transmission Rate |
150Mbps |
Insertion Loss |
<0.2dB |
Protective Line |
1,2,3,6 |
Net Weight |
0.06kg |
Failure Mechanism |
Communication line in the short circuit or disconnects |
Housing |
Aluminum alloy |
Dimensions |
80*25*25mm |
2.Picture of Single channel Network Surge Protector
3.Transportation of Surge Protector
4.Company and Factory show of Surge Protector
5. Certification of Surge Protector
6.Exhibition of Surge Protector
