10/100/1000M Gigabyte Optical Fiber Media Converter
OFS Series Gigabit Fiber Media Converter can convert Optical-Electric Ethernet signals between 10/100/1000M UTP interface (TX) and 1000M optical fiber interface (FX). The traditional 10/100/1000M gigabit Ethernet can be extended to the distance of 100km through optical fiber link. The performance and quality of the products are excellent because of adopting latest Gigabit IC from USA and Taiwan. 6 Group LED indicated lights could fully monitor the working conditions of converters. It is easy for users to observe and diagnose the failure of converters. OFS Series Gigabit Converters could be used alone; but Converter Card should be inserted to 16 slots RACK supplied by OFS Crop. which is suitable for the use of Network Centre.
Main features
Auto negotiation function allows UTP ports to auto select 10/100/1000M and Full Duplex or Half Duplex.
The UTP port supports the connection of MDI/MDI-X auto crossover.
Multimode Fiber: the max distance up to 224m/ 550m
Singlemode Fiber: the max distance up to 100km
Supporting the max 1536 byte Ethernet packet
Supporting flow control
Adopting internal power supply
