Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > 10/100M Mini Size Media Converter 1310&550nm Single Fiber SM 20Km SC ,supply OEM

10/100M Mini Size Media Converter 1310&550nm Single Fiber SM 20Km SC ,supply OEM

Name: 10/100M Mini Size Media Converter 1310&550nm Single Fiber SM 20Km SC ,supply OEM
Brand: OPTFOCUS
SKU: 107904263
Availability: InStock

10/100M Mini Size Media Converter 1310&550nm Single Fiber SM 20Km SC ,supply OEM thumbnail-1

10/100M Mini Size Media Converter 1310&550nm Single Fiber SM 20Km SC ,supply OEM thumbnail-2

10/100M Mini Size Media Converter 1310&550nm Single Fiber SM 20Km SC ,supply OEM photo-1

10/100M Mini Size Media Converter 1310&550nm Single Fiber SM 20Km SC ,supply OEM photo-2

US$ 20 - 28 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OPTFOCUS

Model Number:

OFS-WS01S/02S-20

Contact Supplier Request Quote Chat Now

Shenzhen Optfocus Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OPTFOCUS

Model Number OFS-WS01S/02S-20

10/100M Ethernet Mini Fiber Media Converter

OPTFOCUS Series Mini Fiber Media Converter is the conversion equipment of Ethernet optical-electronic signals between 10/100M UTP interface (TX) and 100M Fiber interface (FX). The traditional 10/100M Fast Ethernet can be extended to the distance of 120km through optical fiber link. The performance and quality of the products are excellent because of adopting latest IC. 3 Group LED indicated lights could fully monitor the working conditions of Converters. It is easy for users to observe the network operations. The Series products with reasonable price are especially designed for network users.OPTFOCUS Series Converters could be used alone; but Converter Card should be inserted to 16 slots RACK supplied by OPTFOCUS. Crop., which is suitable for the use of Network Centre.

Main features

The transmission of a channel optical signals can be completed by single fiber. It has doubled in quantity of fiber data transmission compared with twin fiber type.

Auto negotiation function allows UTP port to auto select 10M or 100M and Full Duplex or Half Duplex

UTP port supports MDI / MDI-X auto crossover.

Supporting flow control

Supporting 1552 bytes packet

Extend fiber distance up to 2km for multi-mode fiber and 20-120km for single-mode fiber

Internal circuit of prevented thunder could greatly reduce damage of the converter caused by thunderbolt induction.

Design of external power supply by end-users.

Technical Specifications

Operating standard:

IEEE802.3 10BASE-T Ethernet
IEEE802.3u 100BASE-TX/FX Fast-Ethernet
IEEE802.3x

MAC address table: 1K

Data Buffer :128Kb RAM

Connector: UTP: RJ-45,10/100Mbps; Fiber: SC,100Mbps

Cable:

UTP: Cat. 5 UTP (the max distance up to100m)

Fiber ( Singlemode): 8.3/125, 8.7/125, 9/125, 10/125μm(the max distance up to 90km)

Flow control

Full Duplex:IEEE802.3x

Half Duplex:back pressure

LED: Power, FX , TP.

Power :Input:AC 110~265V or DC:-36V~-72V

Output:DC 12-24V 1A

Conversion mode: Medium conversion

MTBF: 80,000 hours

Ambient temperature:0 ~ +50℃

Storage temperature:-20 ~ +70℃

Humidity:5% ~ 95%

Dimensions:

Power external: 23 (high) x 50 (width) x 54 (length) mm

Fiber Optic Information

Type	Connector	Fiber type	Wavelength	Max. distance	TX power	Sensitivity	Link Budget
OFS-DMS	ST/SC	multimode	850/1310nm	2km	-20~-12dBm	-30dBm	10dBm
OFS-DSS25	SC	singlemode	1310nm	25km	-14~-8dBm	-32dBm	18dBm
OFS-DSS40	SC	singlemode	1310nm	40km	-8~-3dBm	-33dBm	25dBm
OFS-DSS60	SC	singlemode	1310nm	60km	-3~0dBm	-36dBm	33dBm
OFS-DSS80	SC	singlemode	1550nm	80km	-10~-5dBm	-35dBm	25dBm
OFS-DSS100	SC	singlemode	1550nm	100km	-5~0dBm	-36dBm	31dBm
OFS-DSS120	SC	singlemode	1550nm	100km	-1~3dBm	-36dBm	35dBm
OFS-W01S/02S-20	SC	20km	1310/1550nm	20km	-14~-6dBm	-32dBm	18dBm
OFS-W01S/02S-40	SC	40km	1310/1550nm	40km	-8/-10~-3dBm	-35dBm	27/25dBm
OFS-W01S/02S-60	SC	60km	1490/1550nm	60km	-5/-7~0dBm	-37dBm	32/30dBm
OFS-W01S/02S-80	SC	80km	1490/1550nm	80km	-3/-5~2dBm	-37dBm	34/32dBm

Order Information

Model	Product description
OFS-DMS	10/100M multimode MINI Converter, the max optical fiber distance up to 2 or 5 km.
OFS-DSS-XX	10/100M singlemode MINIConverter, max optical fiber distance from 20 to 120 km, xx for the amount of distance.
OFS-W01S/02S -xx	10/100M Singlemode Single Fiber MINI Converters must be used and orderd in couples. One set of WS01S must be connected with another set of WS02 for using. WS01S transmitted optical wavelength 1310nm, receive optical wavelength 1550nm; WS02S transmitted optical wavelength 1550nm, receive optical wavelength 1310nm. The max distance of fiber is up to 20, 40, 60, 80km. XX is the amount of distance.
