Xenon Aging Machine
Xenon Aging Machine
Main Technicial Parameters
| Model | XL Series | XL-S Series | ||
| XL-500 | XL-750 | XL-S-500 | XL-S-750 | |
| Internal dimensions (mm) | 500*760*500 | 950*950*850 | 500*760*500 | 950*950*850 |
| Overall dimensions (mm) | 1200*1150*1480 | 1280*1320*1980 | 1200*1150*1480 | 1280*1320*1980 |
| Specimen Capacity | 28 | 34 | 28 | 34 |
| Holder size (mm) | 80*150 | 80*150 | 80*150 | 80*150 |
| Technical structure | ||||
| Distance between sample and lamp | Approx. 350mm | Approx. 450mm | Approx. 350mm | Approx. 450mm |
| Irradiance Ranges W/m2 | 100~1200 W/M2 @ 280nm ~ 800nm | 40 ~ 180 W/M2 @ 300nm ~ 420nm | ||
| Xenon lamp power | 4500W (Lamp life time: 1600 hours) | |||
| Xenon Arc Lamp | 1 Water Cooled xenon arc lamp with inner quartz and outer borosilicate filter. | |||
| Temperature range | Ambient ~100℃ | |||
| Relative Humidity range | 50~98% R.H | |||
| BPT Temperature | 35 ~85℃ | |||
| Water spray time | 1~9999H59M, settable | |||
| Water spray cycle | 1~240 minute, interval settable | |||
| Control system | ||||
| Controller | programmable color display touch screen controller | |||
| PC Link with software, R-232 interface | ||||
| Temperature Sensor | PTR Platinum Resistance PT100Ω/MV A-class | |||
| Temperature Resolution | ± 0.001 ℃ | |||
| Humidity Sensor | Dry and wet bulb sensor | |||
| Humidity Resolution | ± 1%RH | |||
| Radiometer | Tolerance: ±5% | |||
| Heating system | Independent Nichrome electronic heating system | |||
| Cooling system | French TECUMSEH compressor | |||
| Humidification system | External isolation, stainless steel surface evaporation humidifier | |||
| Water supply system | Automatic water supply, Water purification system, Water save | |||
| Circulatory system | Cold resistance and low noise centrifugal fan | |||
| Material | ||||
| Exterior material | Steel Plate with protective coating | |||
| Interior material | SUS304 stainless steel | |||
| Insulation window | Double thermo stability silicone rubber sealing | |||
| Environmental conditional | 5℃ ~ +30℃ , ≤ 85% RH | |||
| Nominal power | 8000W | 10600W | 7000W | 8500W |
| Power Supply | AC380V 50HZ | AC380V 50HZ | AC380V 50HZ | AC380V 50HZ |
Test Area And Sample Holder
Test area is made of stainless-steel.
Standard sample holder, holder size is 8*15cm.
Specimen capacity is XL-500 is 28 pcs, XL-750 is 34 pcs.
If need special holder, should confirm in advance
Chamber equipped with 1pc of Xenon lamp, which is water cooling.
Xenon Lamp Power is 4500W .
Xenon lamp service life is 1600hours.
Programmable Color Touch Screen Type
5.7'' programmable color display touch screen controller
Program: 100 groups in 999 sections
R-232 interface
PC link with software
Cooling System
TECUMSEH compressor from France
Environment friendly refrigerant R404A
Humidity System
External isolation, stainless steel surface evaporation humidifier
Water Spraying
Automatic water supply, water purification system, water saving.
Water reservoir 50 Liter
Radiometer & Sensors
Temperature sensor PT-100 A class
Resolution: ± 0.001 ℃
Humidity sensor Dry and wet bulb
Resolution: ± 1%RH
Irradiance Radiometer
Tolerance: ±5%
Black panel thermometer
Xenon Aging Machine
Export Standard Wooden Package
3 Years Warranty
