70mm2 HMWPE Cable
US$ 0.45 - 19.6
MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Hengfei
Model Number:
HMWPE
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou or according to your requirement
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Kynar/HMWPE Cable for Cathodic ProtectionUS$ 0.53 - 20.7MOQ: 500 Meters -
16mm2 Kynar/HMWPE CableUS$ 0.53 - 20.7MOQ: 500 Meters
-
10mm2 Cathodic Protection Cable Kynar/HMWPE CableUS$ 0.53 - 20.7MOQ: 500 Meters
-
16mm2 Cathodic Protection Cable Kynar/HMWPE CableUS$ 0.53 - 20.7MOQ: 500 Meters
-
25mm2 Cathodic Protection Cable Kynar/HMWPE CableUS$ 0.53 - 20.7MOQ: 500 Meters
Place of Origin
Hunan, China
Brand Name
Hengfei
Model Number
HMWPE
Conductor Material
Copper
Insulation Material
Other, high molecular weight polyethylene
Number of Conductors
Single core
Application
Athodic protection applications
Specifications
1.StandardConductor:ASTM Specification B-8,insulation: ASTM D-1248
2.Certificate:CQC ,3C
3.Strict QC
70mm2 HMWPE cable
Application
A direct burial DC cable for use in cathodic protection applications such as anode lead wires, header cables, structure connections, test leads and more. The product can also be used for submerged installations in water tanks, offshore structures and other similar applications.
The polyethylene insulation is durable, abrasion resistant and flexible but has temperature and chemical limitations.
This cable insulation color is usually black (standard). However, other custom colors are available depending the quantity purchased.
Standards
- Conductor
Stranded copper conductor conforms to ASTM Specification B-8.
- Insulation
Insulation is high molecular weight polyethylene conforming to ASTM D-1248, Type 1, Class A, Category 5, Grades E4 & E5. Tensile Strengths Jl, J3. Available with high density polyethylene (Types II, III, IV) Class B & C (all colors).
Construction
Annealed, uncoated, stranded copper conductor, HMW polyethylene black insulation. Surface or indent printed. Custom printing available.
Tecnical Data
