Help CenterCDP-24S (Double Rows) In-line Liquid Filling Machine
Related Products
-
CDP-1W-250L Weighing Filling MachineUS$ 8,000 - 15,000MOQ: 1 Set -
CCG3000-8B Automatic Servo Piston Filling MachineNegotiableMOQ: 1 Set
-
CCG500-1 Semi-Automatic Piston Filling MachineUS$ 1 - 2,000MOQ: 1 Set
-
CDP-24S Automatic Filling Machine (Double Row)US$ 1 - 19,500MOQ: 1 Set
-
50ml ~ 500ml Skincare Cream & Lotion Filling MahinceUS$ 16,000 - 33,000MOQ: 1 Set
Specifications
1.China utility model patent.2.Production capacity:Can reach 9000bottles/hour
3.Double rows filling---Saving space
Technical performance:
The machine adopts the fixed flow channel parameter, controlling the the flowmeter by controlling the filling time to realize filling for different measurement.The filling process is under control of PLC.All operations complete on the touching screen. .
The machine fills in two rows,under the action of two-in-one conveying belt,into next working procedure,enhancing production efficiency.It is an ideal kind of packaging equipment for chemical,pesticide,daily chemical,medicine,food and cosmetic industry etc.
It has properties of reliable and stable performance.high efficiency,good adaptability, changing the measuring specification in minutes(no need to change any components,just adjust ),eco-friendly outer frame,filling without drop and leak.
Peformance advantages:
1. Control system---- Mitsubishi PLC control system, random minitrimming filling measurement
2. Control panel-----5.6 in. colour screen,easy-operated,stable and reliable
3. Function improvement-----The feeding nozzle is equipped with filling blocker. This machine can realize diving filling according to the material properties.(this function can be selected)
4. Real-time alarm-----Automatic alarming when the fault happens,automatic stopping and alarming
when the system appears serious breakdown.
5.Electrical elements----Adopting international famous brand to ensure the remarkable quality, stability and high precision.
Machine elements----The parts contacted with the material use the 316 high-quality stainless steel and non-poisonous, anti-corrosive PTEF hose.Other machine parts use the 304 high-class stainless steel.
6. Counting detection----Real- time counting,reflecting the output directly.
7. Filling detection----No-bottle no-filling,it will not conduct filling if the bottles are not enough.
8. Expansion function----We can carry out special configuration according to the customers requirements.(material airtight,heating and sterilizing etc.)
9. Maintenance condition----Fully accords to the GMP requirements, easy to disassemble and clean.
10. Functional upgrading----We have designed intelligent weighing feedback system to realize the
unmanned debugging function and more preciser filling measurement.
11.Changing specification----No need to change any components,easy to realize changing the bottle types by simple adjusting.
12.Environmental protection configuration----Equipped with eco-friendly frame, realizing more cleaner and sanitary operation environment.
13.Intellectual property----This machine has gained the China utility model patent.
Technical parameters:
1. Filling head:24 heads (24/28/32 heads can be selected)
2. Application: 40-100ml(various bottle shapes)
3.Voltage: 220V/380V
4.Suitable bottle diameter: 40mm-100mm
5. Filling error: ±1%
6. Filling Speed: ≤9000bottles/hour(100ml water for test)
7.Overall Dimension: 2000mm × 1400mm × 2500mm
8. Machine weight: 600 kg
9. Air source requirements:stable 0.55Mpa-0.65Mpa air
