Home > Products > Dust Test Chambers > Laboratory Dust Test Chamber
Laboratory Dust Test Chamber
- 200 Unit / Units per Month
- Shanghai Guangzhou Tianjing Shenzhen Dailian HK
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shaanxi, China | Brand Name: | LIB | Model Number: | DI-800 |
Power: | Electronic | Usage: | Universal Testing Machine |
Product Description
Laboratory Dust Test Chamber
Model | DI-800 | DI-1000 |
Internal dimensions (mm) | 800*1000*1000 | 1000*1000*1000 |
Overall dimensions (mm) | 1050*1420*1820 | 1250*1420*1820 |
Performance index | ||
Metal mesh diameter | 50um | |
Nominal spacing between lines | 75um | |
The Talcum powder amount | 2kg ~ 4kg/m3 | |
Fight time | 0 ~ 99H59M | |
Fan cycle time | 0 ~ 99H59M | |
Specimen power outlet | Dust-proof socket AC220V 16A | |
Control system | ||
Controller | 5.7" programmable color touch display controller | |
PC Link with software, R-232 interface | ||
Vacuum system | Equipped with vacuum pump, a pressure gauge, air filter, pressure regulating triple, connecting tube | |
Circulating fan | Enclosed alloy low-noise motor, multi-vane centrifugal fan | |
Heating system | Independent Nichrome electronic heating system | |
Power supply | 380V 50HZ; | |
Safety Devices | Electric leakage, short circuit, Over-temperature, motor overheating Over-current protection/ Power failure memory function for controller | |
Note: The test chamber can meet the standards IEC60529 GB2423,GB4706, GB4208, and satisfy the experiment requirements of parts enclosure protection grade for household appliances for DIN,low-voltage apparatus,automobiles,motorcycle. It can’t meet a sand and dust test with wind source according to GJB150. |
Design and Construction
Test area and shelf
Test area is made of stainless-steel
A shelf is located above the sieve and funnel, you can put
Test specimen on it.
Load of shelf is 50kg( if you need heavier load,
please confirm with us).
And we reserve power interface for test specimen.
Control Panel
5.7" programmable color touch display controller
99 programs 99 sections
R-232 interface
PC Link with software
Dust circulation
During test, dust is blown in workroom by air, then fall in funnel through, and cycle blowing by circulating pump to achieve dust circulation blowing in test area.
Vacuum system
Some test specimens need to vacuumize.
Equipped with vacuum pump, a pressure gauge, air filter,
pressure regulating triple, connecting tube.
Sensors
Temperature sensor PT-100 A class
Temperature Resolution: ± 0.01 ℃;
Safety protection
Independent over-temperature protection,
Over-current protection
Over-current circuit breaker
Earth leakage protection
Motor overheating
Power supply and Wiring
380V, 50 Hz 10% +/-
Three-phase five little system
Installation conditions
Ambient Temperature 5℃~+30 ℃ ≤85% RH
Test chamber should be away from wall over 80 cm to
adequately ventilate and heat dissipation
Export Standard Wooden Package
Packed in standard export packing material.
Can be used for Sea, Air,Railway, Truck transportation.
Model | Packing Dimension | Gross weight | Delivery Time |
DI-800 | 1500*1800*2200 mm | 530kg | 20days |
DI-1000 | 1700*1900*2200 mm | 700kg | 20days |
Three years Warranty ; Lifelong Service
Question: I need chambers very urgently, do you have stock ?
LIB: we have no stock, our standard delivery is 25 days , if you need in urgent , we can speed up the production ,will short to 15 days , customer should notice before order .
Question: How about your LIB payment terms?
LIB: Our payment is 50% with order, and 50% before delivery.
Question: Can LIB arrange delivery to our office (Lab)?
LIB: Yes, LIB can arrange shipping to your country and to your office ( Lab) by sea, by air, by train and by truck on conditions FOB, CFR, CIF, DDU and DDP for customers .
Question: Can we visit your plant before order?
LIB: We welcome and sincerely invite you or your team to visit our plant, we will help you to arrange hotel and pick you up from airport.
Question: Have you sold chambers to our country?
LIB: Now LIB climatic test chambers sold to more than 25 countries, like USA, Canada, Russia, UK, Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand Vietnam, Thailand, Iran, Brazil ……and so on .
Question: Can you arrange installations and commissioning in our lab?
LIB: Firstly, for standard chamber we had 5 days commissioning before shipping , you just need link power in your lab, then can start to operate; Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it; Thirdly, some of customized chambers we should to install and teach your team to operate .
Question: How about your warranty?
LIB: It is three years warranty for every LIB’s chamber, and lifetime service. Now LIB has 8 agents in the world, and in Europe (Italy) , America (USA) Middle East(Iran) had service office, we can in first time to solve your problems.
Skype: wendy.lib
website: welcome to visit / to find more details.
