Lab Drying Equipment Classification Horizontal Forced Air Drying Oven
Forced Air Drying Oven
Main Technical Parameters
Model |
0-100 |
0-225 |
0-500 |
0-800 |
0-1000 |
Workroom dimensions mm |
450*450*500 |
500*600*750 |
800*700*900 |
800*1000*1000 |
1000*1000*1000 |
Exterior dimensions mm |
750*880*850 |
800*950*1000 |
1100*1100*1300 |
1100*1450*1400 |
1300*1400*1400 |
Technical structure | |||||
Temperature range |
RT+10℃~+250 ℃ (Max to 400℃) |
||||
Temperature fluctuations |
± 0.5 ℃ |
||||
Temperature deviation |
± 2.0 ℃ |
||||
Heating rate |
about 6 ℃ / min |
||||
Control system | |||||
Controller |
Color Touch Screen Type |
||||
Sensor |
PTR Platinum Resistance PT100 |
||||
Heating system |
Independent Nichrome electronic heating system |
||||
Circulatory system |
Cold resistance and low noise centrifugal wind wheel |
||||
Used material | |||||
Exterior material |
Carbon Steel Plate with antistatic hull painting |
||||
Interior material |
SUS304 stainlesssteel |
||||
Insulation window |
Double thermostability silicone rubber sealing |
||||
Standardconfiguration |
1 Cable hole (Φ 50,) cover, 2 sets of shelf, 2 protector tubes, 1 overflow water tube, 1 copy of operating specification |
||||
Timing Function |
0.1~999.9 (S,M,H) settable |
||||
Power Supply |
AC380V 50HZ |
||||
Ambient Temperature |
5℃~+30 ℃ ≤85% RH |
||||
Standard |
GB/T2423.1-2001; GB/T2423.2-2001 |
||||
Test Area And Workroom
Is made of stainless steel;
2 stainless steel shelves (adjustable);
Temperature Air Flow
The real wall of test area with chip-type wind board and return air inlet to achieve air flow
Air flowing out from top of wind board which control air direction, and return into air let to achieve air flow
Sensor
Temperature sensor: PT-100 A class
Resolution: temperature +/-0.01C
Safety Protection
Independent over-temperature protection;
Over-current protection;
Refrigerant high pressure protection switch
Earth leakage protection and so on
Forced Air Drying Oven
Export standard wooden case
LIB INDUSTRY
Frequently Asked Questions
Question: I need chambers very urgently, do you have stock ?
LIB: we have no stock, our standard delivery is 15 days , if you need in urgent , we can speed up the production ,will short to 10 days , customer should notice before order .
Question: How about your LIB payment terms?
LIB: Our payment is 50% with order, and 50% before delivery.
Question: Can LIB arrange delivery to our office (Lab)?
LIB: Yes, LIB can arrange shipping to your country and to your office ( Lab) by sea, by air, by train and by truck on conditions FOB, CFR, CIF, DDU and DDP for customers .
Question: Can we visit your plant before order?
LIB: We welcome and sincerely invite you or your team to visit our plant, we will help you to arrange hotel and pick you up from airport.
Question: Have you sold chambers to our country?
LIB: Now LIB climatic test chambers sold to more than 25 countries, like USA, Canada, Russia, UK, Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand Vietnam, Thailand, Iran, Brazil ……and so on .
Question: Can you arrange installations and commissioning in our lab?
LIB: Firstly, for standard chamber we had 5 days commissioning before shipping , you just need link power in your lab, then can start to operate; Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it; Thirdly, some of customized chambers we should to install and teach.
