Thermal Shock Ovens
Thermal Shock Ovens
Technical Parameters
Model |
0-100 |
0-225 |
0-500 |
0-800 |
0-1000 |
|||||
Internal dimensions (mm) |
400*500*500 |
500*600*750 |
700*800*900 |
800*1000*1000 |
1000*1000*1000 |
|||||
Overall dimensions (mm) |
750*880*850 |
800*950*1000 |
1100*1100*1300 |
1100*1450*1400 |
1300*1400*1400 |
|||||
Temperature range |
Ambient~+250 ℃; Ambient~+400 ℃; Ambient~+900 ℃; |
|||||||||
Temperature fluctuations |
± 0.5 ℃ |
|||||||||
Temperature deviation |
± 2.0 ℃ |
|||||||||
Heating rate |
about 6 ℃ / min |
|||||||||
Controller |
Digital PID Temperature Controller |
|||||||||
programmable color display touch screen, PC Link with software, R-232 interface (Optional) | ||||||||||
Temperature Sensor |
PT100 A-class |
|||||||||
Temperature Resolution |
± 0.1 ℃ |
|||||||||
Heating system |
Independent Nichrome electronic heating system |
|||||||||
Circulatory system |
Cold resistance and low noise centrifugal wind wheel |
|||||||||
Exterior material |
Steel Plate with Protective coating |
|||||||||
Interior material |
SUS304 stainlesssteel |
|||||||||
Insulation window |
Double thermostability silicone rubber sealing |
|||||||||
Standardconfiguration |
2 sets of shelf , 1 copy of operating specification |
|||||||||
Timing Function |
0.1~999.9 (S,M,H) settable |
|||||||||
Environmental conditional |
5℃~+30 ℃ ≤85% RH |
|||||||||
Nominal power |
2500W |
3000W |
3500W |
4500W |
6500W |
|||||
Power Supply |
AC220V 50HZ |
AC220V 50HZ |
AC220V 50HZ |
AC220V 50HZ |
AC380V 50HZ |
|||||
Structure characteristics:
1. Stainless steel plate plus (41090) power for hull painting.
2. It integrates three control systems of PLC, HMI and SOC in fine way.
3. ETAc820 touch-control colored screen as operating interface of TEMI.
4. Protection module for safe voltage can withstand voltage can reach 500V.
5. High-sense Fast AIT monitoring.
6. Automatic safety protection switch.
7. It can separately raise temperature.
8. It utilizes unique BTHC flat constant temperature mode.
9. It has air supply and circulating system.
Control system:
TEMI880 touch-type temperature programmable controller
Operating interface: LED display
Temperature and humidity controller: touch-type LED controller
Setting mode: touching type
Running mode: setting-up running and programmed running
Program: 100 groups in 1000 sections
Resolution: temperature: ± 0.1 ℃;
Input: platinum thermal resistance
Control mode: PID control
Communication function: LAN network interface
Implementation and meet the standards
1.GB/T10589-1989 temperature test chambers;
2.GB/T10592-1989 high-temperature test chambers;
3.GJB/150.3-1986 :high temperature test
4.GJB/150.4-1986 : temperature test
Safety device
Independent over-temperature protection, over-current protection, over-current circuit breaker, earth leakage protection and so on.
1.Operation ambient temperature: +5~+ 30℃
2.Power supply:AC220±10%V 50±0.5Hz single-phase double-wire + protective grounding wire/ AC380±10%V 50±0.5Hz three-phase four-wire+ protective grounding wire.
More pictures for the Heat Oven
Lifelong Service
Warranty: 3 Years
Service:
Our company will repair the product, if the product, the material of the parts, the design and manufacturing of the products made by our company arise hardware problems caused by product itself rather than human error within three years warranty period since the date of delivery.
Firstly, we can provide the spare parts with you. And also provide the solution about the trouble of the products.
Secondly, Please send back the apparatus, which will be repaired by our company.
Lastly, we would like to appoint our technical engineer to your company to repair the apparatus.
Question: I need chambers very urgently, do you have stock ?
LIB: we have no stock, our standard delivery is 20 days , if you need in urgent , we can speed up the production ,will short to 18 days , customer should notice before order .
Question: How about your LIB payment terms?
LIB: Our payment is 50% with order, and 50% before delivery.
Question: Can LIB arrange delivery to our office (Lab)?
LIB: Yes, LIB can arrange shipping to your country and to your office ( Lab) by sea, by air, by train and by truck on conditions FOB, CFR, CIF, DDU and DDP for customers .
Question: Can we visit your plant before order?
LIB: We welcome and sincerely invite you or your team to visit our plant, we will help you to arrange hotel and pick you up from airport.
Question: Have you sold chambers to our country?
LIB: Now LIB climatic test chambers sold to more than 25 countries, like USA, Canada, Russia, UK, Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Vietnam, Thailand, Iran, Brazil ……and so on .
Question: Can you arrange installations and commissioning in our lab?
LIB: Firstly, for standard chamber we had 5 days commissioning before shipping , you just need link power in your lab, then can start to operate; Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it; Thirdly, some of customized chambers we should to install and teach your team to operate .
Question: How about your warranty?
LIB: It is three years warranty for every LIB’s chamber, and lifetime service. Now LIB has 8 agents in the world, and in Europe (Italy) , America (USA) Middle East(Iran) had service office, we can in first time to solve your problems.
